Vishay MAL205659102E3 Aluminum Capacitors
Power Standard Miniature Snap-In aluminum electrolytic capacitors designed for general purpose, industrial, and audio/video systems. Featuring long life of 12,000 hours at 85°C, high ripple current capability, and RoHS compliance, these capacitors are suitable for smoothing, filtering, power supplies, and energy storage in pulse systems. Available in two and three-terminal versions with various case sizes (22x25mm to 35x50mm), they provide reliable performance under demanding electrical and environmental conditions, marked with rated capacitance, voltage, date code, and polarity indicators.
Vishay MAL205659102E3 Aluminum Capacitors Specifications:
- Nominal case size: 22 x 25 mm to 35 x 50 mm
- Rated capacitance range: 470 to 47,000 UF
- Tolerance: ±20%
- Rated voltage: 10V to 100V, 200V to 450V
- Temperature range: -40°C to +85°C
- Endurance: 12,000 hours at 85°C
- Useful life: 210,000 hours at 40°C
- Shelf life: 500 hours at 0V, 85°C
- RoHS compliant
- Features: Pressure relief, charge/discharge proof, high ripple current, keyed polarity available
- Case material: Cylindrical aluminum case with insulating sleeve, pressure relief top
- Mounting: Two-terminal and three-terminal snap-in versions with mounting holes
- Marking: Capacitance, voltage, date code, polarity, climatic category
- Impedance: Low ESR at 100Hz, impedance variation with frequency and temperature
- Electrical characteristics: Leakage current < specified limits, low inductance (~19 nH), high ripple current capability
Buy the Buy Vishay Aluminum Capacitors Power Standard Miniature Snap-In Part Number MAL205659102E3 Online
Order Vishay Aluminum Capacitors Power Standard Miniature Snap-In online today for dependable power supply filtering and energy storage. These long-life capacitors deliver high ripple current, reliable performance, and are RoHS compliant, suitable for industrial, audio/video, and power conversion applications. Available in various sizes with two- and three-terminal configurations, they ensure optimal performance in demanding environments. Easy to install and marked with detailed specifications, they are ideal for engineers seeking durable, high-quality capacitors for demanding electronic systems.
Get Vishay Aluminum Capacitors Power Standard Miniature Snap-In MAL205659102E3 today—designed for long-lasting durability and reliable power filtering.
Frequently Asked Questions
Where can I buy Vishay MAL205659102E3?
You can click on the BUY or RFQ button to purchase MAL205659102E3 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MAL205659102E3?
You can download the MAL205659102E3 datasheet or visit the Vishay website for support.
Who is the manufacturer of MAL205659102E3?
Vishay
