Vishay MAL210212103E3 High Ripple Current Aluminum Capacitor
These high ripple current aluminum electrolytic capacitors are designed for buffering, filtering, motor drives, inverters, UPS, and pulsed power supplies. They feature long useful life of up to 15,000 hours at +85°C, large case sizes including up to 90 mm x 220 mm, and are available with screw terminals and pressure relief seals. Their low ESR and high ripple current ratings make them suitable for demanding industrial applications requiring reliable power decoupling and energy storage with extended longevity.
Vishay MAL210212103E3 High Ripple Current Aluminum Capacitor Specifications:
- Capacitance Range: 220 UF to 1 F
- Voltage Range: 25 V to 450 V
- Case Sizes: Up to 90 mm x 220 mm
- Useful Life: 10,000 to 15,000 hours at +85°C
- Operating Temperature: -40°C to +85°C
- Endurance: 2000 hours at 85°C for some series
- Ripple Current: Rated up to 85°C, with multipliers based on frequency and airflow
- Low ESR: Max ESR at 100 Hz varies by series, typically below 100 mΩ
- Pressure Relief: Yes
- RoHS Compliant: Yes
- Material: Aluminum electrolytic with non-solid electrolyte
Buy the Vishay 101/102 PHR-ST – Reliable Aluminum Capacitors for Industrial Applications
Discover the reliable performance of Vishay high ripple current aluminum electrolytic capacitors. Perfect for industrial buffering, filtering, motor drives, and UPS systems, these capacitors offer long life up to 15,000 hours at +85°C. Available in large case sizes up to 90 mm x 220 mm, with screw terminals, low ESR, pressure relief, and RoHS compliance, they're built to meet demanding power and energy storage needs. Order online today for fast delivery and trusted quality in your projects.
Order your Vishay Series101/102 PHR-ST high ripple current capacitors today and ensure your industrial power systems have dependable, long-lasting energy storage.
Frequently Asked Questions
Where can I buy Vishay MAL210212103E3?
You can click on the BUY or RFQ button to purchase MAL210212103E3 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MAL210212103E3?
You can download the MAL210212103E3 datasheet or visit the Vishay website for support.
Who is the manufacturer of MAL210212103E3?
Vishay
