Vishay MAL214097602E3 High-Temperature Surface-Mount Aluminum Capacitor
The Vishay 140 CRH Aluminum Capacitors are high-temperature, surface-mount chip electrolytic capacitors designed for demanding industrial and automotive applications. Featuring non-solid electrolyte, self-healing properties, RoHS compliance, and high endurance at 125°C, they offer rated capacitance from 10 µF to 4700 µF, rated voltages between 6.3V and 63V, and a category temperature up to +125°C. Their robust design supports high temperature reflow soldering. Suitable for filtering, buffering, and smoothing in automotive, industrial, and telecom equipment, they ensure long service life and reliability in high temperature environments.
Vishay MAL214097602E3 High-Temperature Surface-Mount Aluminum Capacitor Specifications:
- Nominal case sizes: 8x8x10 mm to 18x18x21 mm
- Rated capacitance: 10 µF to 4700 µF
- Tolerance on capacitance: + 20%
- Rated voltage: 6.3 V to 63 V
- Category temperature range: -55°C to +125°C
- Endurance: 1000 h to 3000 h at 125°C
- Useful life: 1500 h to 5000 h at 125°C, up to 350,000 h at 40°C
- RoHS compliant, lead-free reflow solderable
- Suitable for high-temperature reflow soldering according to JEDEC J-STD-020
- Designed for automatic placement, suitable for surface-mount technology
- Operates with ripple currents and features self-healing properties
- Climatic category IEC 60068: 55/125/56
- Includes multiple optional mounting configurations and packaging on reels
- Electrical characteristics: ripple current up to 2200 µF at 100 kHz and applicable surge and reverse voltages
- Tested for mechanical reliability, vibration proof, and long-term stability
Buy the Vishay 140 CRH U+2013 Reliable Aluminum Capacitors for Industrial Applications
Order Vishay 140 CRH aluminum capacitors online today for reliable high-temperature performance. Designed for demanding industrial, automotive, and telecom applications, these surface-mount electrolytic capacitors combine robust construction, RoHS compliance, and excellent endurance up to +125°C. Their specified capacitance range from 10 µF to 4700 µF and voltage ratings from 6.3V to 63V ensure versatility. Perfect for smoothing, filtering, and buffering in complex circuits, they offer long service life, high reliability, and seamless integration into automated manufacturing processes for professional electronics assembly.
Get Vishay 140 CRH today—built for high-temperature environments and long-lasting durability.
Frequently Asked Questions
Where can I buy Vishay MAL214097602E3?
You can click on the BUY or RFQ button to purchase MAL214097602E3 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MAL214097602E3?
You can download the MAL214097602E3 datasheet or visit the Vishay website for support.
Who is the manufacturer of MAL214097602E3?
Vishay
