Vishay MAL219366471E3 Aluminum Electrolytic Capacitors
Vishay Aluminum Electrolytic Capacitors are compact, high-reliability components designed for industrial applications such as solar inverters, motor controls, and power supplies. Rated voltages up to 500 V and capacitance ranges from 47 UF to 820 UF, these capacitors feature improved ripple current handling, long endurance life of 5000 hours at 105°C, and RoHS compliance. They are available in snap-in terminal configurations with various case sizes, offering excellent filtering and smoothing performance for demanding electronic systems.
Vishay MAL219366471E3 Aluminum Electrolytic Capacitors Specifications:
- Nominal case size: 22x25 mm to 35x60 mm
- Rated capacitance: 47 UF to 820 UF
- Tolerance on capacitance: +20%
- Rated voltage range: 400 V, 450 V, 500 V
- Category temperature range: -40°C to +105°C
- Endurance test at 105°C: 2000 hours
- Useful life at 105°C: 5000 hours
- Shelf life at 0 V, 105°C: 1000 hours
- Ripple current: Up to 500 V, rated at 100 Hz, 105°C
- Leakage current: Less than 0.01 CA at rated voltage after 5 minutes
- Surge voltage: > 400 V versions at 1.1 times Up
- Equivalent series resistance (ESR): Max 1.3x specified limit at 100 Hz
- Maximum impedance at 10 kHz: Dependent on case size
- Physical configurations: 2-terminal and 3-terminal snap-in
- Operating temperature: -40°C to +105°C
Buy the Vishay 193 PUR-SI – Reliable Aluminum Electrolytic Capacitors for Industrial Applications
Order Vishay 193 PUR-SI aluminum electrolytic capacitors online today for your industrial power needs. With voltages up to 500 V, capacitance from 47 UF to 820 UF, and proven endurance of 5000 hours at 105°C, these reliable components enhance filtration, smoothing, and energy storage applications. Designed for long-term performance, they feature RoHS compliance and come in various case sizes with snap-in terminals for easy installation. Ensure your systems operate efficiently with these high-quality, durable capacitors—shop now for fast delivery and expert support.
Get Vishay 193 PUR-SI today—built for long-lasting durability and high ripple current handling in industrial power systems.
