Vishay MAL225051102E3 High Vibration Aluminum Capacitor
The high vibration resistance aluminum electrolytic capacitor series offers a long useful life of up to 10,000 hours at 105°C, with very low impedance and ESR. Designed for power supplies, filtering, and buffering in industrial, automotive, and telecommunications systems, it features radial leads, cylindrical aluminum case, and blue sleeve insulation. Suitable for demanding environments, the series is AEC-Q200 qualified, charge and discharge proof, with excellent ripple current capability and stability. Available in various sizes from 16 x 20 mm to 18 x 40 mm, it ensures reliable performance under high vibration and temperature conditions.
Vishay MAL225051102E3 High Vibration Aluminum Capacitor Specifications:
- Nominal case sizes: 16 x 20mm to 18 x 40mm
- Rated capacitance: 330 UF to 8200 pF
- Tolerance on capacitance: +20% (code: M)
- Rated voltage: 10V to 100V
- Temperature range: -55°C to +105°C
- Endurance: 3000h to 10,000h at 105°C depending on size
- Useful life: 7,000h to 10,000h at 105°C
- Ripple current: Rated at 100 kHz, 105°C, Ia values vary per size
- Vibration resistance: Up to 50g, no damage or electrolyte leakage
- RoHS compliant, charge/discharge proof, and AEC-Q200 qualified
- Dimensions and packaging vary by size, with maximum lengths up to 42.5mm
- Impedance at 100kHz: as specified in datasheet
- ESR: typical at 20°C and 100Hz, varies with frequency
- Leakage current: ≤ 0.01 CR at 2 min, where CR is capacitance in μF
- Compliant with IEC 60384-4, EN130300 standards
Buy the Vishay Series 250 High Vibration Capacitors: MAL225051102E3
Order the Vishay 250 series aluminum electrolytic capacitor MAL225051102E3 online today. Crafted for demanding environments, this capacitor offers exceptional vibration resistance, stability, and long life. Ideal for power supplies, filtering, and buffering in industrial, automotive, and telecommunications systems, it features a cylindrical aluminum case, radial leads, and blue insulation sleeve. With a range of sizes and high ripple current capabilities, this high reliability capacitor ensures performance and durability in critical applications. Buy now for reliable, long-term operation.
Get Vishay 250 series aluminum electrolytic capacitor MAL225051102E3 today—built for high vibration resistance and long-lasting power stability.
Frequently Asked Questions
Where can I buy Vishay MAL225051102E3?
You can click on the BUY or RFQ button to purchase MAL225051102E3 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MAL225051102E3?
You can download the MAL225051102E3 datasheet or visit the Vishay website for support.
Who is the manufacturer of MAL225051102E3?
Vishay
