Vishay MBA02040C1213FRP00 Thin Film Resistor
These professional thin film leaded resistors are highly reliable components suitable for telecommunication, industrial, automotive, and medical applications. They feature excellent stability, wide resistance range from 0.22 to 22 MΩ, and are compliant with RoHS and halogen-free standards. Manufactured with precision deposition of metal alloy on ceramic, they offer low TCR, high power dissipation up to 1.0W, and are tested rigorously for stability and performance under various environmental conditions. The resistors are available in various sizes with leaded, radial, and surface-mount options, ensuring dependable operation in demanding electronic circuits.
Vishay MBA02040C1213FRP00 Thin Film Resistor Specifications:
- Resistance Range: 0.22 Q to 22 MQ
- Resistance Tolerance: ±5 %, ±41 %, ±405 %
- Temperature Coefficient: +50 ppm/K; +25 ppm/K
- Rated Dissipation: 0.4W (0204), 0.6W (0207), 1.0W (0414)
- Operating Voltage: 200 V (0204), 350 V (0207), 500 V (0414)
- Operating Temperature Range: -55°C to 155°C
- Peak Film Temperature: 155°C
- Insulation Voltage: 300 V (0204), 500 V (0207), 800 V (0414)
- Resistance Drift at 1000h: <0.25% (0204), <0.5% (0207), <0.2% (0414)
- Dimensions: MBA/SMA 0204 - 1.6mm D, 3.6mm L; MBB/SMA 0207 - 2.5mm D, 6.5mm L; MBE/SMA 0414 - 4.2mm D, 11.9mm L
- Material: Metal film on ceramic with leaded, wire-wound or surface-mount configurations
- Compliance: RoHS, Halogen-Free, IECQ-CECC approved for CECC versions
- Flammability: UL 94V-0
- Shock and Vibration: Conforms to IEC 60068 series testing
- Environmental Test: Damp heat, cold, dry heat, and high humidity tested
- Application: Low-noise, high-reliability electronics for telecom, industrial, automotive, and medical sectors
Buy the Buy Vishay Beyschlag Professional Thin Film Leaded Resistors Part Number MBA02040C1213FRP00 Online
Purchase your Vishay Beyschlag Thin Film Resistor MBA02040C1213FRP00 now online to benefit from superior stability, wide resistance options, and high power dissipation. These resistors are ideal for telecommunication, industrial, automotive, and medical electronics where consistent performance is critical. Manufactured with high-precision deposition processes, they provide low TCR, excellent environmental resilience, and RoHS compliance. Secure reliable, proven technology for your critical systems by ordering direct from our online store today and integrate dependable components into your designs with confidence.
Order your Vishay Series MBA02040C1213FRP00 high-stability thin film resistor today and ensure reliable performance in your demanding electronic applications.
Frequently Asked Questions
Where can I buy Vishay MBA02040C1213FRP00?
You can click on the BUY or RFQ button to purchase MBA02040C1213FRP00 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MBA02040C1213FRP00?
You can download the MBA02040C1213FRP00 datasheet or visit the Vishay website for support.
Who is the manufacturer of MBA02040C1213FRP00?
Vishay
