Vishay MBR20100CTM34W High-Voltage Schottky Rectifier
The MBR20100CT-M3 is a high-voltage dual Schottky rectifier with Trench MOS barrier technology, ideal for high-frequency rectification in power supplies, DC/DC converters, and protection circuits. Constructed in a TO-220AB package with matte tin-plated leads, it features low forward voltage drop and high surge current capacity, ensuring efficient performance and reliability. This device operates within a junction temperature range of -65°C to +150°C, capable of blocking voltages of 100 V and sustaining surge currents up to 150 A, making it suitable for demanding electronics applications requiring high efficiency and durability.
Vishay MBR20100CTM34W High-Voltage Schottky Rectifier Specifications:
- Case: TO-220AB
- Maximum Repetitive Peak Reverse Voltage: 100 V
- Maximum DC Blocking Voltage: 100 V
- Maximum Average Forward Rectified Current at Tc=133°C: 10 A per diode
- Peak Forward Surge Current: 150 A
- Operating Junction and Storage Temperature Range: -65°C to +150°C
- Forward Voltage Drop: 0.65 V at 20 A, 128°C
- Reverse Current at 25°C: 100 μA
- Thermal Resistance: 2.0°C/W junction-to-ambient
- Material: Molding compound UL 94 V-0
- Leads: Matte tin plated, solderable
Buy the Buy Vishay MBR20100CT-M3 Part Number 20100CT-M3 Online
Purchase the Vishay MBR20100CT-M3 today for reliable high-voltage rectification in power electronics. Designed with advanced Trench MOS Schottky technology, it offers low forward voltage, high surge current capacity, and efficient operation. Encased in a durable TO-220AB package, this rectifier excels in high-frequency switching power supplies, DC/DC converters, and polarity protection circuits. Its wide operating temperature range of -65°C to +150°C ensures excellent performance under demanding conditions. Order now for fast delivery and long-lasting durability in your electronic projects.
Get Vishay MBR20100CT-M3 today—built for high-voltage switching applications with low forward voltage and robust surge current capacity.
Frequently Asked Questions
Where can I buy Vishay MBR20100CTM34W?
You can click on the BUY or RFQ button to purchase MBR20100CTM34W from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MBR20100CTM34W?
You can download the MBR20100CTM34W datasheet or visit the Vishay website for support.
Who is the manufacturer of MBR20100CTM34W?
Vishay
