Vishay MKP1847530354K2 AC Filtering Capacitor
Metallized polypropylene film capacitor designed for AC filtering applications, with high peak current capabilities, long lifetime, RoHS compliant, and high temperature rating up to 105°C. Suitable for use in UPS systems, renewable energy grid interfaces, harmonic filters, and welding equipment, this radial type capacitor features a sealed plastic case with resin encapsulation for durability and safety. It conforms to IEC standards and offers robust mounting options to withstand vibration and shock, making it ideal for demanding electronic filtering applications.
Vishay MKP1847530354K2 AC Filtering Capacitor Specifications:
- Dielectric: Polypropylene film
- Construction: Mono and internal serial construction
- Maximum continuous AC voltage: 230V to 440V depending on model
- Capacitance range: 1 UF to 70 UF
- Capacitance tolerance: +5% and 10%
- Maximum application temperature: 105°C
- Case material: Plastic, sealed with resin, flame retardant
- Terminals: Tinned wire
- Life expectancy: > 60,000 hours at Unac
- Self inductance: <1 nH per mm lead spacing
- Insulation resistance: >10,000 s at 500 V
- Standards: IEC 61071, IEC 60068
Buy the Vishay Series MKP1847 AC Filtering Capacitor: MKP1847530354K2
Order the Vishay MKP1847530354K2 AC filtering capacitor today and ensure reliable, high-performance filtering for your power electronics. Designed to withstand harsh environments, it features metallized polypropylene film, RoHS compliance, and a sealed resin encapsulation for safety and durability. Ideal for UPS systems, renewable energy grid interfaces, and harmonic filters, this capacitor supports high peak currents and long operational life. With optimal thermal properties and robust construction, it offers excellent insulation resistance and minimal inductance, making it the perfect choice for demanding industrial applications requiring precision filtering and stability.
Get Vishay MKP1847530354K2 today—built for precision and long-lasting durability in AC filtering and harmonic suppression.
Frequently Asked Questions
Where can I buy Vishay MKP1847530354K2?
You can click on the BUY or RFQ button to purchase MKP1847530354K2 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MKP1847530354K2?
You can download the MKP1847530354K2 datasheet or visit the Vishay website for support.
Who is the manufacturer of MKP1847530354K2?
Vishay
