Vishay MKP1848C61512JP5 DC-Link Capacitor
The MKP1848C61512JP5 is a high-performance metallized polypropylene film capacitor designed for DC-link applications. It offers reliable operation with long service life, high ripple current capabilities, low ESR, and low ESL. Suitable for renewable energy inverters, UPS, battery chargers, and motor drives, this capacitor provides excellent thermal stability up to 105°C, with a voltage rating of 600V at 70°C and robust construction for vibration and shock resistance. Its sealed resin encapsulation ensures durability in demanding environments, making it ideal for power electronics and industrial systems.
Vishay MKP1848C61512JP5 DC-Link Capacitor Specifications:
- Capacitance Range: 1 µF to 500 µF
- Voltage Ratings: 500 V at 85°C, 600 V at 70°C, 800 V at 105°C
- Temperature Range: -55°C to +105°C, rated up to 105°C
- Equivalent Series Resistance (ESR): Low, typical at specified frequencies
- Insulation Resistance: >10,000 S after 1 min at test voltage
- Lifetime: Over 100,000 hours at Unc and 70°C
- Dielectric Material: Metallized polypropylene film
- Construction: Mono wound cell with resin potting, flame retardant
- Self-inductance: <1 nH per mm lead spacing
- Dimensions: Vary by model, typical case sizes in datasheet
- Mounting: Radial, sealed with resin for durability
- Stand-off Pin Hole Diameter: As per model specifications
Buy the Vishay Series MKP1848C DC-Link Capacitor: MKP1848C61512JP5
Purchase your Vishay series MKP1848C61512JP5 DC-link capacitor now and benefit from its long service life, low ESR, high ripple current capacity, and sealed design. Perfect for renewable energy inverters, UPS systems, battery chargers, and motor drives, this capacitor guarantees dependable performance under demanding thermal and electrical conditions. Available with sealed resin encapsulation and radial mounting, it ensures durability, vibration resistance, and stability at high temperatures up to 105°C. Buy online today for efficient power management and enhanced project reliability.
Order your Vishay Series MKP1848C61512JP5 high-performance power capacitor today and ensure reliable operation in your industrial and power electronics projects.
