Vishay MKT1813310405 Film Capacitor
The MKT1813 is a high-quality film capacitor designed for various electronic applications, including filtering, bypassing, and timing circuits. Constructed with metallized polyester dielectric film and plastic-wrapped, epoxy resin sealed encapsulation, it offers excellent stability up to 100°C and RoHS compliance. Available in a wide capacitance range from 470 pF to 22 µF, it features tinned lead wires, multiple voltage ratings, and detailed marking for easy identification. Ideal for low-voltage interference suppression and timing circuits, it ensures reliability in industrial and consumer electronics.
Vishay MKT1813310405 Film Capacitor Specifications:
- Capacitance range: 470 pF to 22 µF
- Capacitance tolerance: +20%, +10%, +5%
- Maximum temperature: 100°C
- Dielectric: Polyester film
- Electrodes: Metallized
- Construction: Mono and internal series
- Encapsulation: Plastic-wrapped, epoxy resin sealed, flame retardant
- Leads: Tinned wire
- Rated DC voltage: 63 V, 100 V, 250 V, 400 V, 630 V, 1000 V
- Rated AC voltage: 40 V, 63 V, 160 V, 200 V, 220 V
- Climatic testing: IEC 60068-1 55/100/56
- Physical dimensions: D varies with capacitance; L varies with voltage and size, typically 11.0 mm to 26.5 mm
- Pull test on leads: Minimum 20 N
- Bending test: 2 bends through 90° with 10 N tensile force
- Pulse withstand: Up to 84 V/μs depending on voltage and capacitance
- RoHS compliant
Buy the Vishay Series MKT Capacitor Reliable Film Component: MKT1813310405
Order the Vishay MKT1813 film capacitor online today and benefit from superior reliability for filtering, bypassing, and timing applications. Designed with metallized polyester dielectric film, it offers excellent stability at temperatures up to 100°C and RoHS compliance. Available in a broad capacitance range from 470 pF to 22 µF, with various voltage ratings, detailed markings, and sealed encapsulation, ensuring durability and ease of installation in industrial, consumer, and electronic equipment. Secure your supply now for dependable electronic performance.
Get Vishay MKT1813 today—built for precision, stability, and long-lasting durability in electronic filtering and timing circuits.
Frequently Asked Questions
Where can I buy Vishay MKT1813310405?
You can click on the BUY or RFQ button to purchase MKT1813310405 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part MKT1813310405?
You can download the MKT1813310405 datasheet or visit the Vishay website for support.
Who is the manufacturer of MKT1813310405?
Vishay
