Vishay P13LFL103MAB10 Sealed Potentiometer
The fully sealed cermet potentiometer offers high durability and stability, suitable for military and professional applications. Featuring a rugged sealed case, it provides a precise electrical travel of 270°, with a power rating of 1.5 W at 70°C. It includes options for locking, panel sealing, and special shafts, ensuring versatility. It has a low temperature coefficient of 75 ppm/°C, excellent dielectric strength of 2000 V, and an IP67 sealing rating for environmental resistance. The device is qualified under RoHS and CECC standards, making it ideal for demanding industrial and military use.
Vishay P13LFL103MAB10 Sealed Potentiometer Specifications:
- Electrical travel: 270° + 10°
- Resistance Range: 1 kΩ to 2.2 MΩ
- Power rating: 1.5 W at 70°C
- Dielectric strength: 2000 V RMS
- Sealing: Fully sealed, IP67
- Temperature range: -55°C to +125°C
- Mechanical travel: 300° ± 5°
- Operating torque: 2.85 oz.in (nom)
- End stop torque: Max 3.1 Ib.in
- Material: Cermet resistive element
- Insulation resistance: >10 MΩ at 300 V
- End resistance: approx. 10 Ω
- Terminals: 3, pure Sn
- Weight: 6 to 18 g
- Environmental: Climatic category 55/125/56
Buy the Vishay P13L – Reliable Potentiometer for Industrial Applications
Enhance your industrial, military, or professional projects with the high-performance sealed potentiometer. Featuring a rugged IP67 sealed case, 270° electrical travel, and a power rating of 1.5 W at 70°C, this device offers superior durability and stability. Its low temperature coefficient of 75 ppm/°C ensures consistent performance over temperature variations. The potentiometer is RoHS and CECC qualified, with a range of options including locking mechanisms and panel sealing, making it ideal for critical applications requiring reliability and precision.
Get Vishay P13L today—designed for precision, durability, and environmental resistance in demanding industrial environments.
Frequently Asked Questions
Where can I buy Vishay P13LFL103MAB10?
You can click on the BUY or RFQ button to purchase P13LFL103MAB10 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part P13LFL103MAB10?
You can download the P13LFL103MAB10 datasheet or visit the Vishay website for support.
Who is the manufacturer of P13LFL103MAB10?
Vishay
