Vishay PA16NP223MAB15 Rotary Potentiometer with Switch
The P16S and PA16S are innovative rotary potentiometers with integrated switch functionality, suitable for industrial, professional audio, and military applications. The P16S features a cermet resistive element delivering 1 W at 40°C, while the PA16S uses conductive plastic for 0.5 W at 40°C. Both variants offer sealed construction, configurable knobs, and detents with electric cut-off at travel start. Designed for panel mounting, they provide precise resistance control, durability, and optional custom knobs, ideal for diverse electronic and control systems requiring reliable performance.
Vishay PA16NP223MAB15 Rotary Potentiometer with Switch Specifications:
- Resistive Element: Cermet (P16S) or Conductive Plastic (PA16S)
- Electrical Travel: 220° ± 10°
- Power Rating: 1 W at 40°C (P16S), 0.5 W at 40°C (PA16S)
- Resistance Range: 22 kΩ to 10 MΩ with standard series 1-2-4.7-10-22-47-100 kΩ and optional custom values
- Temperature Range: -40°C to +125°C (metallic knob), -40°C to +85°C (plastic knob)
- Protection Grade: IP67
- Mechanical Travel: 300° ± 5°
- End Stop Torque: max 25 N·cm
- Operating Torque: typically 2 N·cm
- Switching: ON/OFF action with 30° ± 25° travel, max switching current 100 mA (PA16S 1 mA), insulation resistance 10 MΩ at 500 V
- Environmental: Sealed, panel sealed, operating temperature up to +125°C, climatic category 40/100/56
- Switch Durability: 10,000 cycles
Buy the Vishay P16S – Reliable Rotary Potentiometer with Switch for Industrial Applications
Order the Vishay P16S potentiometer with integrated switch online today for reliable performance in industrial, military, and audio applications. This rugged, sealed design offers precise resistance control, configurable knobs, and a robust construction suitable for demanding environments. With customizable features and high durability, the P16S ensures your control systems operate smoothly and efficiently. Invest in genuine Vishay components now and enhance your equipment’s reliability and longevity with this high-quality, panel-mount potentiometer with switch functionality.
Get Vishay P16S today—built for durability and precise resistance control in industrial and professional electronic systems.
Frequently Asked Questions
Where can I buy Vishay PA16NP223MAB15?
You can click on the BUY or RFQ button to purchase PA16NP223MAB15 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part PA16NP223MAB15?
You can download the PA16NP223MAB15 datasheet or visit the Vishay website for support.
Who is the manufacturer of PA16NP223MAB15?
Vishay
