Vishay RCWE1206R510FKEA Low Resistance Surface Mount Resistor
This surface-mount thick film chip resistor features extremely low resistance values from 0.01 Ω to 0.976 Ω, suitable for current sensing and shunt applications. Constructed with sulfur-resistant, RoHS-compliant, lead-free solder contacts on Ni barrier layers, they are qualified under AEC-Q200. Available in various sizes including 0402, 0603, 0805, 0612, 1206, and larger, these resistors offer enhanced power ratings, excellent thermal stability, and reliability for demanding electronic circuits. Packaging options include punched paper tape and embossed plastic reels for automated assembly. Designed for high performance and durability in industrial and automotive applications.
Vishay RCWE1206R510FKEA Low Resistance Surface Mount Resistor Specifications:
- Resistance Range: 0.01 Ω to 0.976 Ω
- Resistance Tolerance: 0.5%, 1.0%, 5.0%
- Temperature Coefficient: 100 ppm/°C to 700 ppm/°C depending on model
- Power Rating: Varies by size, up to 0.125 W for 0402, 0.5 W for larger sizes
- Operating Temperature Range: -55°C to +155°C
- Insulation Resistance: > 10⁶ Ω
- Maximum Operating Voltage: >75 V to >300 V depending on size
- Dimensions: 0402 (1.0 x 0.5 mm), 0603 (1.6 x 0.8 mm), 0805 (2.0 x 1.25 mm), 1206 (3.2 x 1.6 mm), etc.
- Material: Metal glaze on ceramic, RoHS and halogen-free
- Packaging: Punched paper reels or embossed plastic reels for automated placement
- Compliance: RoHS, Halogen-free, AEC-Q200 qualified
Buy the Vishay Series Resistors: Extremely Low Resistance Value Chip Resistor 0.01 Ω to 0.976 Ω
Purchase Vishay low resistance surface-mount resistors online today and benefit from reliable, sulfur-resistant, RoHS-compliant components. Designed for current sensing, these resistors come in various sizes with excellent thermal stability, making them ideal for industrial and automotive electronics. Enjoy fast shipping and excellent customer service when ordering from authorized distributors. Ensure your electronics meet high standards of quality and durability by choosing Vishay’s trusted resistor solutions for your demanding projects. Buy now and enhance your circuit's performance with reliable, high-quality resistors.
Order your Vishay Series Resistors with ultra-low resistance today and ensure high reliability in your current sensing and shunt applications.
Frequently Asked Questions
Where can I buy Vishay RCWE1206R510FKEA?
You can click on the BUY or RFQ button to purchase RCWE1206R510FKEA from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part RCWE1206R510FKEA?
You can download the RCWE1206R510FKEA datasheet or visit the Vishay website for support.
Who is the manufacturer of RCWE1206R510FKEA?
Vishay
