Vishay TCLT1006 Optocoupler
The TCLT1006 series is a high-performance optocoupler featuring a phototransistor output in a compact SOP-4L package. Designed for safe electrical isolation, it offers a CTR ranging from 100% to 300%, making it suitable for switchmode power supplies, microprocessor systems, and digital interface applications. With a maximum collector-emitter voltage of 70 V and a CTR typical of 130-260%, it ensures reliable performance, extended temperature range from -55°C to +100°C, and RoHS compliance. Its construction provides low coupling capacitance, high creepage distance, and UL1577, CSA recognition, ensuring safety and durability in demanding environments.
Vishay TCLT1006 Optocoupler Specifications:
- Input Reverse Voltage: 6 V
- Input Forward Current: 60 mA
- Input Power Dissipation: 100 mW
- Maximum Junction Temperature: 125°C
- Output Collector-Emitter Voltage: 70 V
- Output Emitter-Collector Voltage: 7 V
- Output Collector Current: 50 mA
- Peak Collector Current: 100 mA
- Total Power Dissipation: 250 mW
- Ambient Operating Temperature Range: -55°C to +100°C
- Storage Temperature Range: -55°C to +125°C
- Isolation Voltage (RMS): 5000 V
- Insulation Resistance (500 V): >10^8 Ω
- Partial Discharge Voltage: 2 kV
- Insulation Distance: 0.40 mm
- Creepage Distance: 8.0 mm
- Cconsistent with DIN EN 60747-5-2
Buy the Buy Vishay Optocoupler Part Number TCLT1006 Online
Purchase your Vishay TCLT1006 optocoupler online today and enhance your electronic projects with a reliable, high-CTR optocoupler offering superior electrical isolation. Ideal for switchmode power supplies, microcontroller interfaces, and safety-critical applications, this compact SOP-4L package features a CTR of 130-260%, maximum collector-emitter voltage of 70 V, and RoHS compliance. Ensure your system's safety, performance, and durability by ordering online now for fast delivery and expert support.
Order your Vishay Series TCLT1006 optocoupler today and ensure reliable isolation for power supplies, safe communication, and high-performance digital interfaces.
Frequently Asked Questions
Where can I buy Vishay TCLT1006?
You can click on the BUY or RFQ button to purchase TCLT1006 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part TCLT1006?
You can download the TCLT1006 datasheet or visit the Vishay website for support.
Who is the manufacturer of TCLT1006?
Vishay
