Vishay TNPW0603330KBEEA Precision Resistor
The TNPW0603330KBEEA is a high stability thin film flat chip resistor designed for precision applications in modern electronics. Offering excellent moisture resistivity, environmental stability, and sulfur resistance verified by ASTM B 809, it is suitable for test and measuring equipment, medical devices, industrial, and automotive use. With a resistance range from 47Ω to 332kΩ and a temperature coefficient of +25 ppm/K, it features rated dissipation of 0.125 W and an operating voltage up to 75V, ensuring reliable performance over a wide temperature range from -85°C to 155°C.
Vishay TNPW0603330KBEEA Precision Resistor Specifications:
- Size: 0603 (RR1608M)
- Resistance Range: 47Ω to 332kΩ
- Resistance Tolerance: ±1%, ±0.5%, ±0.1%
- Temperature Coefficient: +25 ppm/K
- Rated Dissipation: 0.125 W
- Operating Voltage: 75V maximum
- Permissible Film Temperature: 155°C
- Operating Temperature Range: -85°C to 155°C
- Maximum Resistance Change at Rated Dissipation: <0.10% after 8000 hours
- Material: Thin film resistive element
- Compliance: RoHS, AEC-Q200 qualified
- Sulfur Resistance: Verified according to ASTM B 809
- Dimensions: Length 1.55mm, Width 0.85mm, Height 0.45mm
- Mass: approximately 2 mg
Buy the Vishay TNPW0603 U–Reliable Precision Resistor for Industrial Applications
Experience the high reliability and stability of Vishay TNPW0603 precision resistors for your electronic projects. These resistors offer excellent moisture resistivity, sulfur resistance, and environmental stability, making them ideal for medical devices, industrial equipment, and automotive systems. With a resistance range of 47Ω to 332kΩ, tolerance options, and a low power dissipation of 0.125 W, they deliver accurate performance across a wide temperature range from -85°C to 155°C. Perfect for demanding applications requiring stability and durability.
Get Vishay TNPW0603 today—built for precision and long-lasting durability in demanding electronic applications.
Frequently Asked Questions
Where can I buy Vishay TNPW0603330KBEEA?
You can click on the BUY or RFQ button to purchase TNPW0603330KBEEA from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part TNPW0603330KBEEA?
You can download the TNPW0603330KBEEA datasheet or visit the Vishay website for support.
Who is the manufacturer of TNPW0603330KBEEA?
Vishay
