Vishay WYO103MCMCF0KR AC Suppression Capacitor
These Class Y safety capacitors from Vishay are designed for electromagnetic interference suppression in electronic circuits, rated for 250VAC with a tolerance of ±20%. They feature ceramic dielectric Y5U, operating temperature from -40°C to +125°C, and comply with standards including IEC 60384-14. Suitable for line-by-pass and antenna coupling applications, these capacitors consist of ceramic discs with silver-plated sides, balanced with tinned copper leads. They are coated with UL 94 V-0 flame-retardant epoxy resin, offering high reliability and a wide range of capacitance values from 1.0 nF to 12 nF, with robust insulation resistance over 6000 MΩ at 500 V.
Vishay WYO103MCMCF0KR AC Suppression Capacitor Specifications:
- Capacitance range: 1.0 nF to 12 nF
- Rated voltage: 250 Vac (Y2), 440 Vac (X1)
- Tolerance: ±20%
- Operating temperature: -40°C to +125°C
- Dielectric: Ceramic Y5U
- Clamp: Radial mounting
- Insulation resistance: >6000 MΩ at 500 V
- Dissipation factor: max. 2.5% at 1 kHz
- Material: Ceramic disc, silver-plated on both sides
- Lead configuration: Straight or kinked leads, lead spacing 5.0 mm or 7.5 mm
- Coating: Flame-retardant epoxy resin UL 94 V-0
- Test voltage: 2500 V AC for 2s, 1500 V AC for 60s
- Certifications: IEC 60384-14, UL 60384-14, CSA E60384-1
Buy the Vishay Series WYO AC Suppression Capacitors: WY0102MOMKR
Secure your electronic devices with Vishay WYO series AC suppression capacitors, designed for high reliability and safety. Rated for 250VAC with a wide capacitance range of 1 to 12 nanofarads, these ceramic Y5U capacitors are perfect for electromagnetic and radio-frequency interference suppression. Featuring ceramic discs with silver-plated sides, they comply with IEC, UL, and CSA standards. Their flame-retardant epoxy coating and robust insulation resistance ensure safety and durability. Buy online today for dependable EMI filtering in your electronic applications, ensuring compliance and long-lasting performance.
Get Vishay WYO103MCMCF0KR today—optimized for electromagnetic interference suppression and long-term reliability.
Frequently Asked Questions
Where can I buy Vishay WYO103MCMCF0KR?
You can click on the BUY or RFQ button to purchase WYO103MCMCF0KR from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part WYO103MCMCF0KR?
You can download the WYO103MCMCF0KR datasheet or visit the Vishay website for support.
Who is the manufacturer of WYO103MCMCF0KR?
Vishay
