WURTH ELEKTRONIK 15400594F3590 Infrared Round LED
The Würth Elektronik 15400594F3590 is a surface mount infrared LED designed for a wide range of general electronic equipment applications. This component emits high-intensity infrared light and is characterized by its compact size and robust design. It is suitable for applications requiring infrared illumination, such as remote controls, optical sensors, and industrial automation systems. The LED is RoHS compliant, indicating adherence to environmental standards, and operates reliably within a temperature range of -40°C to +85°C. Safety precautions should be observed when handling and operating the LED, including avoiding direct eye exposure.
WURTH ELEKTRONIK 15400594F3590 Infrared Round LED Specifications:
- Power Dissipation: 220 mW
- Peak Forward Current: 1000 mA
- Continuous Forward Current: 100 mA
- Reverse Voltage: 5 V
- ESD Threshold HBM: 2000 V
- Operating Temperature: -40 up to +85 °C
- Storage Conditions: in original packaging, < 40 °C, < 75 % RH
- Moisture Sensitivity Level: 1
- Peak Wavelength: 940 nm
- Centroid Wavelength: 940 nm
- Radiant Intensity: 10-30 mW/sr
- Forward Voltage: 1.3-2 V
- Spectral Bandwidth: 50 nm
- Reverse Current: 10 µA
- Viewing Angle: 30°
- RoHS Approval: Compliant [2011/65/EU&2015/863]
- REACh Approval: Conform or declared [(EC)1907/2006]
- Halogen Free: Conform [JEDEC JS709B]
Buy the 15400594F3590 WURTH ELEKTRONIK Infrared Round LED | myMectronic
Purchase the Würth Elektronik 15400594F3590 Infrared Round LED securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 15400594F3590?
You can click on the BUY or RFQ button to purchase 15400594F3590 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 15400594F3590?
You can download the 15400594F3590 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 15400594F3590?
WURTH ELEKTRONIK
