WURTH ELEKTRONIK 61003621121 Dual SMT Pin Header
The WR-PHD Dual SMT Pin Header by Wurth Elektronik is a high-reliability, 2.54mm pitch connector designed for digital and electronic applications requiring secure, durable connections. Made from copper alloy with gold plating, it features a black PABT insulator with UL94V-0 flammability rating. Rated for 3 A current, it withstands Voltages up to 250 V, with 25 mating cycles durability. Suitable for PCB mounting, it is compliant with RoHS and REACH standards, ideal for automation, control, and communication equipment demanding high performance and safety.
WURTH ELEKTRONIK 61003621121 Dual SMT Pin Header Specifications:
- Pitch: 2.54 mm
- Pins: 36
- Pin to Pin (Middle): 43.18 mm
- Length: 45.72 mm
- Contact Material: Copper Alloy
- Contact Plating: Gold
- Insulator Material: PABT
- Insulator Flammability Rating: UL94V-0
- Color: Black
- Rated Current: 3 A
- Working Voltage: 250 V AC
- Withstanding Voltage: 500 V for 1 min
- Contact Resistance: Max 20 mΩ
- Insulation Resistance: Min 1000 MΩ
- Durability: 25 mating cycles
- Temperature Range: -40°C to +105°C
- Certifications: RoHS Compliant, REACH, UL Approval
- Soldering Profile: Preheat 150-200°C, max. 120 sec, ramp-up 3°C/sec, peak temperature around 260°C, no reflow exceeding 8 mins
- Storage: Use within 12 months of shipment, avoid direct sunlight, store in original packaging
Buy the Buy Wurth Elektronik SMT Dual Pin Header Part Number 61003621121 Online
Secure your electronic projects with the high-performance Dual SMT Pin Header by Wurth Elektronik. Featuring 36 pins at 2.54mm pitch, gold-plated contacts for optimal conductivity, rated for 3A current and 250V voltage, and durability for 25 mating cycles. Perfect for PCB connections in automation, control systems, and communication devices. Reliable, RoHS compliant, and easy to install, this connector ensures safe, durable electrical contact in demanding environments. Order online today and enhance your electronic design with proven quality and performance.
Buy Wurth Elektronik 61003621121 now and experience unmatched reliability and performance with high-quality PCB connector for your electronic assemblies.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 61003621121?
You can click on the BUY or RFQ button to purchase 61003621121 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 61003621121?
You can download the 61003621121 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 61003621121?
WURTH ELEKTRONIK
