WURTH ELEKTRONIK 61200821721 Angled Box Header
The Würth Elektronik WR-BHD 61200821721 is an angled box header designed for reliable connections in general electronic equipment. With a 2.54mm pitch, it offers a compact and efficient solution for board-to-board or wire-to-board applications. It is RoHS compliant and suitable for a wide range of industrial and commercial applications. This component is not intended for use in safety-critical applications without proper evaluation and agreement.
WURTH ELEKTRONIK 61200821721 Angled Box Header Specifications:
- Dimensions_L: ±0,20 mm
- Dimensions_Pl: ±0,10 mm
- Dimensions_q: 0,64 ±0,01 mm
- Dimensions_2_54: 2,54 ±0,05 mm
- Dimensions_4_50: 4,50 ±0,15 mm
- Dimensions_1: 1 mm
- Dimensions_2: 2 mm
- Dimensions_3_00: 3,00 ±0,15 mm
- Dimensions_8_85: 8,85 ±0,15 mm
- Dimensions_1_84: 1,84 ±0,15 mm
- Dimensions_9_10: 9,10 ±0,15 mm
- Pitch_P: 2.54 mm
- Pin_to_Pin_Middle: 7.62 mm
- Length_L: 17.82 mm
- Insulator_Material: PBT
- Insulator_Flammability_Rating: UL94 V-0
- Insulator_Color: Black
- Contact_Material: Copper Alloy
- Contact_Plating: Gold
- Contact_Type: Stamped
- Operating_Temperature: -40 up to +105 °C
- Rated_Current_IR: 3 A
- Working_Voltage: 250 V (AC)
- Withstanding_Voltage: 500 V (AC)
- Contact_Resistance_R: 20 mΩ
- Insulation_Resistance_RISO: 1000 MΩ
- RoHS_Approval: Compliant [ 2011/65/EU&2015/863 ]
- REACh_Approval: Conform or declared [ (EC)1907/2006 ]
- Halogen_Free: Conform [ IEC 61249-2-21 ]
- UL_Approval: E323964
