WURTH ELEKTRONIK 61300621121 Pin Header
The 61300621121 is a 6-position, two-row, 2.54mm pitch pin header with a PA6T insulator. It features gold-plated copper alloy contacts, designed for vertical orientation with through-hole termination. This component complies with UL94V-0 flammability standards and meets Quality Class 3 as per CECC 75 301-802. It has a current rating of 3A and a working voltage of 250VAC, with an insulator resistance exceeding 1000MΩ and a maximum contact resistance of 20mΩ. The pin header is suitable for use in industrial electronics and is compatible with JEDEC lead-free wave soldering processes.
WURTH ELEKTRONIK 61300621121 Pin Header Specifications:
- Pitch: 2.54 mm
- Positions: 6
- Contacts Material: Copper Alloy
- Contact Plating: Gold
- Insulator Material: PA6T
- Flammability Rating: UL94V-0
- Working Voltage: 250 V AC
- Rated Current: 3 A
- Insulation Resistance: > 1000 MΩ
- Contact Resistance: Max 20 mΩ
- Soldering Method: Wave Soldering (JEDEC compliant)
- Durability: 25 mating cycles
- Operating Temperature: -40°C to +105°C
- Compliance: CECC 75 301-802, RoHS, UL Approval
Buy the WURTH ELEKTRONIK 61300621121 – Reliable Pin Header for Industrial Applications
Purchase the high-quality WURTH ELEKTRONIK pin header now and enhance your electronic designs with reliable, industrial-grade connectors. Engineered for durability and safety, this component features a 2.54mm pitch, gold-plated contacts, and UL94V-0 rated PA6T insulator. Its robust design supports current up to 3A at 250VAC and ensures long-lasting performance through multiple mating cycles. Perfect for industrial electronics, automation, and manufacturing environments, order online today for fast delivery and excellent customer support.
Order your WURTH ELEKTRONIK 61300621121 Dual Pin Header today and give your electronic assemblies the dependable quality they deserve, suitable for industrial, automation, and manufacturing projects.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 61300621121?
You can click on the BUY or RFQ button to purchase 61300621121 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 61300621121?
You can download the 61300621121 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 61300621121?
WURTH ELEKTRONIK
