WURTH ELEKTRONIK 62101621021 Dual Pin Header
This SMT straight dual pin header offers reliable electrical connections for electronic assemblies, featuring 1.27mm pitch and gold-plated copper contacts for durability. With a pin-to-pin middle distance of 8.89 mm and a maximum operating temperature of +105°C, it ensures high performance in various applications. The component complies with RoHS standards and is suitable for surface-mount technology, providing secure, precise connections essential for industrial, automation, and electronic equipment. Installation requires adherence to specified reflow profiles for optimal soldering quality.
WURTH ELEKTRONIK 62101621021 Dual Pin Header Specifications:
- Pin Count: 16
- Pin to Pin (Middle) Distance: 8.89 mm
- Length L: 10.16 mm
- Pitch: 1.27 mm
- Contact Material: Copper Alloy
- Contact Plating: Gold
- Insulator Color: Black
- Operating Temperature: ~40°C up to +105°C
- Compliance: RoHS, Lead free
- Rated Current: 1 A
- Working Voltage: 100 VAC
- Withstanding Voltage: 500 VAC for 1 min
- Contact Resistance: Max. 20 mΩ
- Insulation Resistance: Min. 1000 MΩ
- Soldering Profile: Preheat 150-200°C, Max Ramp Rate 3°C/sec, T_max for PB-Free below 260°C
Buy the Wirth Elektronik 62101621021 – Reliable SMT Dual Pin Header for Industrial Applications
Purchase the Dual Pin Header from Wirth Elektronik online today to ensure reliable electrical connections for your electronic projects. Designed for surface-mount applications, it features gold-plated copper contacts and a pitch of 1.27mm, making it ideal for industrial, automation, and electronics manufacturing. The component operates reliably up to +105°C and complies with RoHS standards. Easy to assemble with controlled soldering profiles, this high-quality connector guarantees durability and precise, secure connections. Order now and enhance your product’s performance with trusted, high-standard contact components.
Get Wirth Elektronik 62101621021 today—built for precision and long-lasting durability in electronic connection solutions.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 62101621021?
You can click on the BUY or RFQ button to purchase 62101621021 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 62101621021?
You can download the 62101621021 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 62101621021?
WURTH ELEKTRONIK
