WURTH ELEKTRONIK 62104421021 Dual Pin Header
This SMT straight dual pin header features a 1.27mm pitch, gold-plated copper alloy contacts, and is designed for reliable connections in electronic assemblies. Ideal for high-density circuit configurations, it complies with RoHS standards and withstands temperatures up to +105°C. Suitable for automation and control systems, it provides robust mechanical stability and low contact resistance. The component is packaged in units of 20, with UL94 V-0 flammability rated insulators, ensuring safety and durability in various industrial electronic applications.
WURTH ELEKTRONIK 62104421021 Dual Pin Header Specifications:
- Pitch: 1.27 mm
- Contact Material: Copper Alloy
- Contact Plating: Gold
- Contact Type: Stamped
- Insulator Color: Black
- Operating Temperature: -40°C to +105°C
- Rated Current: 1 A
- Working Voltage: 100 VAC
- Withstanding Voltage: 500 VAC for 1 min
- Contact Resistance: 20 mΩ max.
- Insulation Resistance: 1000 MΩ min.
- Package: 20 units per package
- Material: Insulator made with UL94 V-0 flammability rating
- Compliance: RoHS, Lead-Free
- Dimensions: Pin to pin middle 26.67 mm, length 27.94 mm
Buy the Wirth Elektronik 62104421021 – Reliable SMT Dual Pin for Industrial Applications
Experience high reliability with the Dual Pin Header designed for dense, industrial electronic applications. Featuring a 1.27mm pitch, gold plated contacts, and UL94 V-0 rated insulators, it ensures durable, safe connections even in demanding environments. Perfect for automation systems, control modules, and circuit boards, this component offers excellent electrical performance with low contact resistance and high temperature tolerance. Purchase online today to benefit from quick delivery and assured quality for your industrial electronic projects.
Get Wirth Elektronik 62104421021 today—built for precision and long-lasting durability in electronic connectors.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 62104421021?
You can click on the BUY or RFQ button to purchase 62104421021 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 62104421021?
You can download the 62104421021 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 62104421021?
WURTH ELEKTRONIK
