WURTH ELEKTRONIK 65503503515303 RF SMA Connector
This SMA straight plug is designed for reliable connections in RF applications, featuring a gold-plated brass body and PTFE insulator for enhanced performance and durability. It is compatible with flexible RG174 cables, offering impedance of 50 ohms and a working temperature range of -20°C to +80°C. The connector supports up to 500 mating cycles, with a maximum VSWR of 1.3 at DC to 1 GHz, ensuring minimal signal loss. It is RoHS compliant and suited for high-frequency, precision RF systems demanding robust, stable connections.
WURTH ELEKTRONIK 65503503515303 RF SMA Connector Specifications:
- Connector Type: SMA Straight Plug
- Material: Brass body, PTFE insulator
- Plating: Gold, min. 0.076 µm over Nickel
- Impedance: 50 Ω
- Maximum VSWR: 1.3 at DC to 1 GHz
- Frequency Range: DC to 1 GHz
- Working Temperature: -20°C to +80°C
- Mating Cycles: 500
- Insertion Loss: 0.25 dB max at 1 GHz
- Insulation Resistance: 1000 MΩ at 500 V DC, 120 sec
- Withstanding Voltage: 750 V RMS, 60 sec
- Connector Compatibility: RG174 flexible cables
- RoHS Compliant: Yes
- Connector Material: Brass with gold plating
- Heat shrink tubing: PE, black
- Center Contact Plating: Gold, min. 0.76 µm
- Retention Force: 267 N min.
- Assembly: Solder or crimp connection options
Buy the Würth Elektronik SMA – Reliable RF Connectors for Industrial Applications
Enhance your RF connectivity with Würth Elektronik SMA straight plug, featuring a durable gold-plated brass body, PTFE insulator, and high-performance specifications. Designed for flexible RG174 cables, it ensures minimal signal loss and excellent impedance matching up to 1 GHz frequency. With a maximum VSWR of 1.3, it offers reliable, stable connections essential for precision RF applications. Ideal for professional electronics, testing equipment, and communication systems, this connector is RoHS compliant and easy to install for ensuring high-quality RF performance in industrial environments.
Buy Würth Elektronik SMA straight plug with gold-plated brass body now and experience unmatched reliability and signal integrity for high-frequency RF systems.
