WURTH ELEKTRONIK 687324124422 FPC Connector ZIF Vertical
The Würth Elektronik 687324124422 is a ZIF vertical FPC connector designed for secure and reliable connections with flexible printed circuits. Its ZIF design allows for easy insertion and removal without requiring tools, minimizing stress on the FPC. Constructed with phosphor bronze contacts and tin plating, this connector offers excellent conductivity and corrosion resistance. It is RoHS compliant and suitable for a wide range of general electronic equipment applications, excluding those requiring high safety or reliability standards such as aerospace or medical devices. Always consult Würth Elektronik's precaution guide for proper handling.
WURTH ELEKTRONIK 687324124422 FPC Connector ZIF Vertical Specifications:
- Dimensions: 0.2 ±0.05 mm
- Article Properties: 0.5, 1.3 ±0.15
- Recommended Land Pattern: 0.5, 1.5, 1
- Pin to Pin (Middle): 11.5 mm
- Length: 18.4 mm
- Length (L1): 12.6 mm
- Pitch (P): 0.5 mm
- Durability: 25 Mating cycles
- Insulator Material: LCP
- Insulator Flammability Rating: UL94 V-0
- Insulator Color: Ivory
- Actuator Material: PA9T
- Actuator Flammability Rating: UL94 V-0
- Actuator Color: Black
- Contact Material: Phosphor Bronze
- Contact Plating: 100 (µ”) Tin over 50 (µ”) Nickel
- Contact Type: Stamped
- Solder Tabs: Brass
- REACh Approval: Conform or declared [(EC)1907/2006]
- UL Approval: E323964
- Packaging: Tape and Reel with Cap
- Packaging Unit (Qty): 1000
- Rated Current: 0.5 A
- Working Voltage: 50 V (AC)
- Withstanding Voltage: 250 V (AC) for 1 min
- Contact Resistance: 20 mΩ (max.)
- Insulation Resistance: 100 MΩ (min.)
- Operating Temperature: -25 up to +85 °C
