WURTH ELEKTRONIK 865090468011 Aluminum Electrolytic Capacitor
Wirth Elektronik Aluminum Electrolytic Capacitors are designed for reliable performance in electronic applications operating between -40°C and +85°C. With endurance of 2000 hours at 85°C, they feature a capacitance of 47 µF with a ±20% tolerance, rated voltage of 25 V, and surge voltage of 28.75 V. These high-quality components are suitable for power supply filtering, audio circuits, and general electronic use, conforming to RoHS and REACH standards. Their robust construction ensures durability, with precise dimensions, and safe operation within specified electrical limits, making them ideal for various industrial and consumer electronics.
WURTH ELEKTRONIK 865090468011 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 47 µF ±20%
- Rated Voltage: 25 V
- Surge Voltage: 28.75 V
- Capacitance Test Conditions: 0.25 W/ 120 Hz +20°C
- Operating Temperature: -40°C to +85°C
- Endurance: 2000 hours at 85°C
- Leakage Current: 3 µA max after 2 min at +20°C
- Dissipation Factor: 16% max at 0.25V/120Hz/+20°C
- Physical Dimensions: Length 55 mm max, Diameter 3 mm
- Material: Aluminum oxide dielectric with Tinned Copper leads
- Storage Conditions: 5°C to 35°C, 10–75% RH
- Compliance: RoHS, REACH
Buy the Buy Wirth Elektronik Aluminum Electrolytic Capacitor Part Number 865090468011 Online
Experience the reliability of Wirth Elektronik Aluminum Electrolytic Capacitors, featuring 47µF capacity, 25V rated voltage, and 2000 hours endurance at 85°C. Ideal for power supply filtering, audio applications, and general electronic use, these capacitors meet RoHS and REACH standards. Their robust aluminum oxide dielectric construction ensures durability and stable performance across a wide temperature range. Designed for easy integration with precise dimensions, they are the perfect choice for industrial, consumer, and communication electronics. Order now for superior quality and consistent performance in your projects.
Get Wirth Elektronik Aluminum Electrolytic Capacitor 865090468011 today—built for high reliability and long-lasting performance in electronic circuits.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 865090468011?
You can click on the BUY or RFQ button to purchase 865090468011 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 865090468011?
You can download the 865090468011 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 865090468011?
WURTH ELEKTRONIK
