WURTH ELEKTRONIK 744052120 Power Choke WE-TPC
The Würth Elektronik WE-TPC power choke is a shielded inductor designed to minimize electromagnetic interference (EMI) and optimize power efficiency in electronic circuits. This component is commonly used in DC-DC converters, power supplies, and filtering applications across various industries, including consumer electronics, automotive, and industrial automation. The WE-TPC's robust construction and optimized inductance characteristics contribute to stable and reliable power delivery, while its compact size allows for integration into space-constrained designs. Würth Elektronik ensures high-quality manufacturing and performance standards for this essential power management component.
WURTH ELEKTRONIK 744052120 Power Choke WE-TPC Specifications:
- Inductance: 12.00 µH
- Inductance Tolerance: +- 30%
- DC Resistance (typical): 0.120
- DC Resistance (maximum): 0.160
- Rated Current: 1000 mA
- Saturation Current: 1150 mA
- Self-Resonant Frequency: 35.00 MHz
- Mechanical Dimensions A: 5.8 ± 0.3 mm
- Mechanical Dimensions B: 5.8 ± 0.3 mm
- Mechanical Dimensions C: 1.8 ± 0.2 mm
- Mechanical Dimensions D: 1.90 typ. mm
- Mechanical Dimensions E: 2.0 typ. mm
- Reel Width A: 12.0 ± 1.0 mm
- Reel Width B: 4.00 ± 0.1 mm
- Reel Dimensions a: 178 ± 0.5 mm
- Reel Dimensions b: 20.20 ± 0.1 mm
- Reel Dimensions c: + 0.5 - 1.0, 13.00 mm
- Reel Dimensions d: 50.0 ± 1.0 mm
- Ambient Temperature: -40°C - + 85°C
- Operating Temperature: -40°C - + 125°C
- Ferrite Base Material: Ferrit
- Wire Material: Sn/Ag/Cu - 96.5/3.0/0.5%
