WURTH ELEKTRONIK 744207 Ferrite Bead Filter
This ferrite bead filter is designed for effective suppression of electromagnetic interference in electronic circuits, ensuring compliance with RoHS and REACH standards. Suitable for high-current applications, it maintains low DC resistance and offers excellent impedance at high frequencies, making it ideal for noise filtering in power electronics and signal lines. Its compact surface-mount design supports easy integration into PCB layouts, providing reliable performance in demanding environments up to 125°C operating temperature. The component is packaged in tape and reel, adhering to IEC 60286-3:2007 standards, suitable for automated assembly processes.
WURTH ELEKTRONIK 744207 Ferrite Bead Filter Specifications:
- Inductance: 2 x 35 uH at 100 kHz / 200 mV, ±35%
- Impedance: Max 1100 Q at high frequency
- Rated Current: 2700 mA at 40 KHz
- DC Resistance: 2 x 0.035 Q max
- Leakage Inductance: 63 nH at 1 MHz / 1 mA
- Insulation Test Voltage: 500 V AC max
- Rated Voltage: 80 V AC max
- Operating Temperature: -40°C to +125°C
- Storage Temperature: -20°C to +40°C, 75% RH max
- Soldering: Reflow profile with max ramp-up 3°C/sec, peak temp 217°C, TH/med 60-150 sec
- Package: Tape and reel compliant with IEC 60286-3:2007
- Dimensions depend on specific model but support automated SMT assembly with tape width of 24mm
Buy the WURTH ELEKTRONIK Series WE-SL Ferrite Bead Line Filter: 744207
Shop the WURTH ELEKTRONIK 744207 surface-mount ferrite bead line filter online and experience superior electromagnetic interference suppression. Engineered for high-current power circuits, this SMD component provides low DC resistance and high impedance at high frequencies, ensuring optimal noise filtering in a compact design. Suitable for automated PCB assembly, it adheres to IEC 60286-3:2007 standards, supporting reliable operation in environments up to 125°C. Purchase now for dependable, high-quality EMI suppression in your electronic applications.
Get WURTH ELEKTRONIK 744207 ferrite bead line filter today—designed for efficient noise suppression and reliable high-current performance.
