WURTH ELEKTRONIK 744340300075 High Current Flat Inductor
The Würth Elektronik WE-HCM series is a shielded SMT power inductor designed for high-current applications. Its compact form factor and low DC resistance minimize losses and improve efficiency in DC-DC converters, power supplies, and other power management circuits. The inductor's high saturation current ensures stable operation under demanding conditions, while its excellent temperature stability maintains performance across a wide operating range. Compliant with RoHS and halogen-free standards, the WE-HCM series provides a reliable and environmentally friendly solution for modern electronic designs. Suitable for a wide range of applications including portable devices, automotive electronics, and industrial equipment.
WURTH ELEKTRONIK 744340300075 High Current Flat Inductor Specifications:
- Inductance L: 0.075 µH ±15%
- Rated Inductance LR: 0.075 µH typ.
- Rated Current IR: 27 A max.
- Saturation Current ISAT: 20 A typ.
- DC Resistance RDC: 0.27 mΩ ±15%
- Self Resonant Frequency fres: 106 MHz typ.
- Ambient Temperature: -40 up to +85 °C
- Operating Temperature: -40 up to +125 °C
- Moisture Sensitivity Level (MSL): 1
- Packaging Quantity: 2000
- Material: Polystyrene
