WURTH ELEKTRONIK 7443550101 Power Choke WE-HCI
The WURTH ELEKTRONIK WE-HCI power choke is a critical component in power supply circuits, DC-DC converters, and other applications requiring efficient energy transfer. Its robust design and optimized performance characteristics ensure reliable operation under demanding conditions. The choke's inductance and low DC resistance minimize energy loss and improve overall system efficiency. It is suitable for a wide range of industrial and consumer electronics applications where space is limited and high performance is required.
WURTH ELEKTRONIK 7443550101 Power Choke WE-HCI Specifications:
- A (Dimension): 13.0 ± 1.0 mm
- B (Dimension): 12.8 ± 0.5 mm
- C (Dimension): 4.7 ± 0.3 mm
- D (Dimension): 25 ± 0.5 mm
- E (Dimension): 6.0 ± 0.5 mm
- F (Dimension): 6.4 ± 0.5 mm
- G (Dimension): 3.0 ± 1.0 mm
- Initial Inductance: 10.00 µH
- Rated Inductance: 7.80 µH
- DC Resistance: 14.10 mΩ
- Rated Current: 8.5 A
- Saturation Current: 10.0 A
- Self-Resonant Frequency: 18 MHz
- Operating Temperature: -40°C to +155°C
- Ambient Temperature: -40°C to +105°C
- Base Material: WE-Perm Draht / wire: AIEIW-200
