WURTH ELEKTRONIK 74435582200 SMD Flat Wire Inductor
The Würth Elektronik WE-HCI SMD Flat Wire High Current Inductor is a compact and efficient component designed for a wide range of electronic applications. Featuring a 22µH inductance and a 15.0A rated current, this inductor provides excellent performance in high-current circuits. It operates reliably within a temperature range of -40°C to +125°C, making it suitable for demanding environments. The inductor is RoHS compliant, ensuring environmental responsibility. It's ideal for use in power management, DC-DC converters, and other applications requiring high current handling and efficient energy transfer. Würth Elektronik emphasizes that this product is not intended for use in safety-critical applications without proper evaluation and agreement.
WURTH ELEKTRONIK 74435582200 SMD Flat Wire Inductor Specifications:
- Inductance: 22 µH
- Rated Inductance: 17.7 µH
- Rated Current: 15.0 A
- Saturation Current: 18.0 A
- DC Resistance: 7.00 mΩ
- Self Resonant Frequency: 8.3 MHz
- Test conditions: 100 kHz / 10 mA
- Temperature Range: -40°C to +125°C
- Storage Temperature: -20°C to +40°C, 75% RH max.
- RoHS Compliant: Yes
- Peak Package Body Temperature: See Table H3
- Preheat Temperature Min: 150°C
- Preheat Temperature Max: 200°C
- Preheat Time: 60-180 seconds
- Ramp-up Rate: 3°C/second max.
- Liquidous Temperature: 217°C
- Time Maintained Above Liquidous Temperature: 60-150 seconds
- Time Within 5°C of Peak Temperature: 20-30 seconds
- Ramp-down Rate: 6°C/second max.
Buy the 74435582200 WURTH ELEKTRONIK SMD Flat Wire Inductor | myMectronic
Purchase the WURTH ELEKTRONIK 74435582200 SMD Flat Wire Inductor securely and reliably through our online store.
Buy Now
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 74435582200?
You can click on the BUY or RFQ button to purchase 74435582200 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 74435582200?
You can download the 74435582200 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 74435582200?
WURTH ELEKTRONIK
