WURTH ELEKTRONIK 74437336033 SMD Power Inductor
The Wurth Elektronik WE-LHMI SMD Power Inductor is a surface-mount device designed for efficient power management in various electronic circuits. With an inductance of 3.3µH and a rated current of 4.1A, this inductor provides excellent performance in DC-DC converters, filtering circuits, and other power-related applications. Its low DC resistance minimizes power losses, while the high self-resonant frequency ensures stable operation. The component is not authorized for use in equipment where a higher safety standard and reliability standard is especially required or where a failure of the product is reasonably expected to cause severe personal injury or death.
WURTH ELEKTRONIK 74437336033 SMD Power Inductor Specifications:
- Inductance: 3.3 µH ±20%
- Rated Current: 4.1 A max.
- Saturation Current: 8.4 A typ.
- DC Resistance @ 20°C: 38.0 mΩ max.
- Self Resonant Frequency: 27 MHz typ.
- Test Conditions (Inductance): 100 kHz / 10 mA
- Test Conditions (Rated Current): ∆T = 40 K
- Test Conditions (Saturation Current): |ΔL/L| < 20%
- Operating Temperature Range: -40°C to +125°C
- Storage Temperature: -20°C to +40°C, 75% RH max.
