WURTH ELEKTRONIK 74476402 Wire Wound Inductor
Wurth Elektronik's WE-GF series SMD wire wound inductors are designed for general electronic equipment, offering high reliability and stable inductance of 2.2 uH with a 10% tolerance. Suitable for circuit filtering and power supplies, these inductors operate within -40°C to +105°C, with a rated current of 320 mA and a maximum DC resistance of 1.0 Ω. Their manufacturing specifications include precise dimensions, and adherence to reflow soldering profiles ensures optimal performance in SMT assembly. These components are RoHS and REACH compliant, emphasizing safety and environmental standards.
WURTH ELEKTRONIK 74476402 Wire Wound Inductor Specifications:
- Inductance: 2.2 uH ±10%
- Rated current: 320 mA
- DC Resistance: 1.0 Ω max at 20°C
- Self resonant frequency: 75 MHz typ.
- Q-factor: 30 min. at 7.96 MHz
- Temperature range: -40°C to +105°C
- Storage temperature: -20°C to +40°C
- Operating temperature: -40°C to +105°C
- Lead size: 1210 (size code)
- Soldering profile: Preheat at 150-200°C for 60-120 s, peak temp 245°C
- Compliance: RoHS, REACH
- Material: Wire wound, compatible with SMT reflow processes
- Application: Circuit filtering, power supply modules
Buy the Buy Wurth Elektronik WE-GF Series Inductor Part Number 74476402 Online
Securely purchase the Wurth Elektronik Series74476402 wire wound inductor online. Designed for reliable performance in electronic circuits, this inductor offers 2.2 uH inductance, 10% tolerance, and maximum current of 320 mA. Perfect for circuit filtering and power management, it adheres to RoHS and REACH standards, ensuring safety and environmental compliance. With precise dimensions and a robust SMT design, it is suitable for manufacturing and repair of electronic equipment. Order now to integrate a high-quality, space-efficient inductor into your project and ensure excellent electrical stability and longevity.
Order your Wurth Elektronik Series74476402 wire wound inductor today and enhance your electronic circuits with reliable, space-saving inductive solutions.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 74476402?
You can click on the BUY or RFQ button to purchase 74476402 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 74476402?
You can download the 74476402 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 74476402?
WURTH ELEKTRONIK
