WURTH ELEKTRONIK 7447706100 Shielded Power Inductor
The Würth Elektronik 7447706100 is a shielded power inductor designed for surface mount technology (SMT) applications. It features a 10µH inductance, a rated current of 5.8A, and a saturation current of 7.8A. The component is AEC-Q200 Grade 1 compliant, indicating its suitability for automotive and demanding industrial environments. Its shielded construction minimizes electromagnetic interference (EMI), making it ideal for power management and filtering in a wide range of electronic devices. The inductor is RoHS compliant and conforms to JEDEC JS709B halogen-free standards. It is not intended for use in safety-critical applications without proper evaluation and agreement.
WURTH ELEKTRONIK 7447706100 Shielded Power Inductor Specifications:
- Inductance L: 10 µH ±20%
- Rated Current IR: 5.8 A max.
- Saturation Current ISAT: 7.8 A typ.
- DC Resistance RDC @ 20 °C: 20 mΩ max.
- Self Resonant Frequency fres: 17.6 MHz typ.
- Operating Voltage V: 120 V max.
- Ambient Temperature: -40 up to +110 °C
- Operating Temperature: -40 up to +150 °C
- Moisture Sensitivity Level (MSL): 1
- Halogen Free: Conform [ JEDEC JS709B ]
- Component Qualification: AEC-Q200 Grade 1
- RoHS Approval: Compliant [ 2011/65/EU&2015/863 ]
- REACh Approval: Conform [ (EC)1907/2006 ]
- Packaging: Tape and Reel
- Pull-of force: 0,1 N - 1,3 N
- Tape width: 24 mm
Buy the 7447706100 WURTH ELEKTRONIK Shielded Power Inductor | myMectronic
Purchase the Würth Elektronik 7447706100 Shielded Power Inductor securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 7447706100?
You can click on the BUY or RFQ button to purchase 7447706100 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 7447706100?
You can download the 7447706100 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 7447706100?
WURTH ELEKTRONIK
