WURTH ELEKTRONIK 7448841033 Powerchoke Inductor
The WE-DPC HV SMD Dual Powerchoke is a high-voltage power inductor designed for SMT applications. It features a compact surface-mount SMD package with a recommended land pattern of 5.5 mm. This inductive component exhibits inductance values of 3.3 vH and 33 vH at 100 kHz/100 mV, with a maximum rated current of 1.9 A. It offers a self-resonant frequency of 50 MHz, low DC resistance, and high coupling coefficient of 0.98. Suitable for high-voltage and high-frequency circuits, it ensures reliable electrical performance and thermal stability up to +125°C.
WURTH ELEKTRONIK 7448841033 Powerchoke Inductor Specifications:
- Inductance: 3.3 vH and 33 vH at 100 kHz/100 mV
- Rated Current: 1.9 A at 40KHz
- Saturation Current: 26 A
- DC Resistance: typ. 84 mΩ @20°C, max. 120 mΩ
- Self Resonant Frequency: 50 MHz
- Turns Ratio: 0 1
- Insulation Test Voltage: Max. 1500 Vac
- Rated Voltage: Up to 250 V RMS
- Temperature Range: -40°C to +125°C
- Package Land Pattern: 5.5 mm recommended
- Material: High-voltage capable inductive core
Buy the Buy Wirth Elektronik WE-DPC HV SMD Dual Powerchoke Part Number 7448841033 Online
Purchase the Wirth Elektronik WE-DPC HV SMD Dual Powerchoke online now to enhance your circuit designs with a high-voltage, high-frequency inductor. This surface-mount component offers a compact design, excellent electrical performance, and thermal stability up to +125°C. It features inductance values of 3.3 vH and 33 vH, rated current of 1.9 A, and high coupling coefficient for optimal efficiency. Perfect for RF, power supply, and high-voltage applications, avail this reliable inductive component through our online store for quick delivery and competitive pricing.
Order your Wirth Elektronik WE-DPC HV SMD Dual Powerchoke today and ensure reliable high-voltage inductance for your RF and power circuits.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 7448841033?
You can click on the BUY or RFQ button to purchase 7448841033 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 7448841033?
You can download the 7448841033 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 7448841033?
WURTH ELEKTRONIK
