WURTH ELEKTRONIK 860040273002 Aluminum Capacitor
These are aluminum electrolytic capacitors designed for electronic circuits requiring stable capacitance and high reliability. Rated at 10V, with a capacitance of 220uf and operating temperature up to +105°C, they suit various power supply applications. Featuring a size of 6.3 x 11.0 mm, these capacitors include safety features like a vent for pressure relief and are RoHS & REACh compliant. They are ideal for electronic devices demanding durable, high-performance components with temperature stability and low leakage current.
WURTH ELEKTRONIK 860040273002 Aluminum Capacitor Specifications:
- Capacitance: 220 µF ±20%
- Rated voltage: 10 V DC
- Leakage current: 22.0 µA max after 2 min
- Dissipation factor: 19% typ. at 120Hz
- Ripple current: 340 mA max at 105°C
- Impedance: 0.23 Ω max at 20°C, 100kHz; 0.87 Ω max at -10°C, 100kHz
- Temperature Range: -40°C to +105°C
- Load Life: 4000 hours at +105°C/10V
- Size: 6.3 x 11.0 mm
- Compliance: RoHS & REACh
- Packaging: Suitable for wave soldering, with safety vent
- Storage conditions: 5°C to 35°C, less than 75% RH
- Design includes pressure relief vent to prevent explosion
Buy the Wurth Electronics 860040273002 – Reliable Aluminum Capacitors for Industrial Applications
Purchase the high-quality aluminum electrolytic capacitor rated for 10V and 220uF capacity today online. Its compact size of 6.3 x 11.0mm makes it ideal for power supply and electronic circuit applications, especially where reliability and temperature stability are critical. Designed with a pressure relief vent for safety, this RoHS & REACh compliant component offers low leakage current, high ripple current capacity, and excellent longevity. Buy online now to incorporate a durable and dependable capacitor into your electronic designs with confidence.
Order your Wurth Electronics series aluminum electrolytic capacitor 860040273002 today and ensure durable, high-performance power stability in your electronic projects.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 860040273002?
You can click on the BUY or RFQ button to purchase 860040273002 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 860040273002?
You can download the 860040273002 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 860040273002?
WURTH ELEKTRONIK
