WURTH ELEKTRONIK 860040374004 Electrolytic Capacitor
This aluminum electrolytic capacitor is designed for general electronic equipment, offering reliable performance with a capacitance of 220 uF and a rated voltage of 16 V. It operates effectively from -40°C to +105°C, with a load life of 7000 hours at +105°C. Suitable for applications requiring high stability and durability, it features a vent to release internal pressure safely. Proper handling, including correct polarity and storage, ensures long-term reliability, making it ideal for various electronic projects and industrial uses requiring stable capacitance and temperature tolerance.
WURTH ELEKTRONIK 860040374004 Electrolytic Capacitor Specifications:
- Capacitance: 220 uF
- Rated Voltage: 16 V (DC)
- Operating Temperature Range: -40°C to +105°C
- Load Life: 7000 hours @ +105°C / 16 V
- Leakage Current: 35.2 HA max after 2 minutes
- Dissipation Factor: 16% typ. at 120 Hz
- Ripple Current: 480 mA max at 100 kHz @105°C
- Impedance: 0.18 Q max at 100kHz @20°C, 0.85 Q max at -10°C
- Size: 8.0 x 11.5 mm
- Polarity: negative terminal marked with shorter lead and sleeve markings
- Storage Conditions: 5°C to 35°C, <75% RH
- Max Soldering Temperature: max. 260°C peak for 10 seconds
- Material: Aluminum electrolyte, PVC sleeve
- Compliance: RoHS & REACH
Buy the WURTH ELEKTRONIK 860040374004 – Reliable Electrolytic Capacitors for Industrial Applications
Enhance your electronic assembly with the WURTH ELEKTRONIK electrolytic capacitor, featuring 220 uF capacitance and 16 V rated voltage. Designed for durability and stable performance from -40°C to +105°C, it offers a load life of 7000 hours at high temperature. Ideal for industrial and commercial electronics, it includes safety features like a pressure vent for secure operation. Easily ordered online, it ensures your project benefits from high reliability, effective heat management, and precise specifications for long-term use in critical applications.
Order your WURTH ELEKTRONIK series 860040374004 aluminum electrolytic capacitor today and ensure dependable, high-performance operation in your electronic projects.
