WURTH ELEKTRONIK 861011486022 Aluminum Electrolytic Capacitor
Wurth Elektronik's WCAP-AIG8 Aluminum Electrolytic Capacitor is designed for reliable power storage and filtering in electronic circuits. Featuring a capacitance of 330 µF and a rated voltage of 450 V DC, it operates efficiently across temperatures from -25°C to +85°C. Its compact size of 35.0 x 37.0 mm makes it suitable for space-constrained applications. Suitable for industrial and electronic equipment, this capacitor provides low leakage current, high ripple current capacity, and excellent electrical stability. It is RoHS and REACH compliant, ensuring eco-friendly use.
WURTH ELEKTRONIK 861011486022 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 330 µF
- Rated voltage: 450 V (DC)
- Leakage current after 5 min: 2970 pA max.
- Dissipation factor: 20 % typ. at 120 Hz
- Ripple current: 2290 mA max. at 120 Hz and 85°C
- Operating Temperature: -25°C to +85°C
- Load Life: 2000 hours at +85°C / 450 V
- Storage Conditions: 5°C to 35°C, <75% RH
- Size: 35.0 x 37.0 mm
- Polarity: Anode positive, cathode negative marked on sleeve
- Compliance: RoHS & REACH
- Soldering: Wave soldering, temperature profile compliant with SN-Pb and lead-free standards
- Vent: Pressure relief vent included to prevent explosion during overpressure
- Material: Aluminum case with PVC sleeve
Buy the Wurth Elektronik 861011486022 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Secure the dependable aluminum electrolytic capacitor from Wurth Elektronik with part number 861011486022 today. Perfect for power filtering, energy storage, and ripple suppression in industrial and electronic equipment. Its 330 µF capacitance at 450 V DC provides excellent electrical stability over a wide temperature range of -25°C to +85°C. Compact and RoHS compliant, this capacitor features low leakage current, high ripple capacity, and robust pressure relief vent for safety. Buy online now for reliable performance in your applications!
Order your Wurth Elektronik 861011486022 series aluminum electrolytic capacitor today and enhance your power supply designs with dependable quality for industrial electronics.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 861011486022?
You can click on the BUY or RFQ button to purchase 861011486022 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 861011486022?
You can download the 861011486022 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 861011486022?
WURTH ELEKTRONIK
