WURTH ELEKTRONIK 861111484018 Aluminum Electrolytic Capacitor
This aluminum electrolytic capacitor is designed for electronic equipment, offering reliable performance with a capacitance of 180 µF at 450 V. Operating within -25°C to +105°C, it withstands a load life of 2000 hours at +105°C and 450 V. Suitable for industrial applications, it features a vent mechanism for pressure release, polarity marking, and is RoHS and REACH compliant. Proper storage and handling are emphasized to ensure safety and longevity. Ideal for power supply filtering, voltage stabilization, and other electronic circuit applications requiring high voltage and temperature tolerance.
WURTH ELEKTRONIK 861111484018 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 180 µF
- Rated Voltage: 450 V (DC)
- Operating Temperature: -25°C to +105°C
- Load Life: 2000 hours @ +105°C, 450 V
- Leakage Current: max. 1620 pA after 5 minutes
- Dissipation Factor: 20% at 120 Hz, typical
- Ripple Current: 930 mA max at 120 Hz/105°C
- Polarity: Negative terminal marked with a color band and minus sign
- Vent mechanism: Pressure relief vent to prevent explosion
- Storage Conditions: 5°C to 35°C, less than 75% RH
- RoHS & REACH compliant
- Dimensions: 25.0 x 31.0 mm
Buy the Wurth Elektronik Series Capacitor: 180uF 450V: 861111484018
Order the Wurth Elektronik aluminum electrolytic capacitor today for reliable voltage filtering and power stabilization in industrial and electronic equipment. Designed for safe operation at voltages up to 450V and temperatures from -25°C to +105°C, this capacitor provides a 180 µF capacitance and a load life of 2000 hours at +105°C. RoHS and REACH compliant, it features a pressure vent for safety, clear polarity marking, and durable construction. Perfect for power supply filtering, voltage regulation, and electronic circuit stability, ensuring high performance and safety in your designs.
Get Wurth Elektronik 861111484018 today—built for power stability and long-lasting performance in demanding electronic applications.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 861111484018?
You can click on the BUY or RFQ button to purchase 861111484018 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 861111484018?
You can download the 861111484018 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 861111484018?
WURTH ELEKTRONIK
