WURTH ELEKTRONIK 861141484009 Aluminum Electrolytic Capacitor
The WCAP-AI3H aluminum electrolytic capacitor by Wurth Elektronik is designed for electronic equipment applications, offering a capacitance of 100µF with a rated voltage of 450V DC. Suitable for general electronic uses, it features a temperature range of -25°C to +105°C, with a load life of 3000 hours at +105°C under specified conditions. Its construction includes a vent for pressure relief, polystyrene markings for polarity, and is compliant with RoHS & REACh standards. Ideal for power supply filters, energy storage, and industrial electronics, it ensures reliable operation in demanding environments.
WURTH ELEKTRONIK 861141484009 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 100µF
- Rated Voltage: 450V DC
- Temperature Range: -25°C to +105°C
- Load Life: 3000 hours at +105°C/ 450V
- Leakage Current: 636.4 pA max after 5 minutes
- Dissipation Factor: 20% typ at 120Hz
- Ripple Current: 690mA max at 120Hz/105°C
- Dimensions: 25.0 x 31.0 mm
- Polarity marked with a minus sign and color band
- Storage Conditions: 5°C to 35°C, <75% RH
- Operating Temperature: -25°C to +105°C
- Pressure Vent for safety
- RoHS & REACh compliant
- Suitable for power supply filtering and energy storage in electronic circuits
Buy the Wurth Series WCAP-AI3H Aluminum Electrolytic Capacitor: 100µF 450V DC
Secure your electronic projects with the Wurth Series WCAP-AI3H Aluminum Electrolytic Capacitor. Crafted for high-voltage applications, this 100µF capacitor supports voltages up to 450 volts DC, ensuring robust performance across a wide temperature range from -25°C to +105°C. Its 3000-hour load life at +105°C and compliance with RoHS & REACh standards make it ideal for power supplies, energy storage, and industrial electronics. Order online today for reliable, durable, and safe capacitor solutions that meet demanding technical specifications and safety standards.
Buy Wurth Series WCAP-AI3H aluminum electrolytic capacitor now and experience unmatched reliability and performance in your industrial circuitry.
