WURTH ELEKTRONIK 861141484010 Aluminum Electrolytic Capacitor
The WCAP-AI3H aluminum electrolytic capacitor from Wirth Elektronik offers a capacitance of 120 uF rated at 450 V DC, suitable for industrial power supply filtering and energy storage. It features a operating temperature range of -25°C to +105°C, a lifespan of 3000 hours at +105°C, and conforms to RoHS and REACh standards. Designed with a vent to prevent explosion and marked with polarity indicators, this high-reliability component is ideal for electronic systems requiring stable voltage and ripple performance. It is manufactured with aluminum casing, PVC sleeve, and optimized for robustness in demanding environments.
WURTH ELEKTRONIK 861141484010 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 120 uF
- Rated Voltage: 450 V DC
- Operating Temperature: -25°C to +105°C
- Lifespan: 3000 hours at +105°C/450 V
- Leakage Current: Max. 697.14 pA after 5 minutes
- Dissipation Factor: 20% at 120 Hz
- Ripple Current: Max. 800 mA at 120 Hz and 105°C
- Physical Size: 25.0 x 31.0 mm
- Polarity Marked: Negative terminal with color band
- Vent for pressure relief, safety vent operation in case of overpressure
- Storage Conditions: 5°C to 35°C, <75% RH
- Soldering: Wave soldering compatible, avoid damaging the sleeve
- RoHS & REACH Compliant
- Design: Aluminum casing with PVC sleeve, withstanding high temperatures and mechanical stress in power electronics
- Application: Suitable for filtering, energy storage, voltage stabilization in industrial and power environments
Buy the Buy Wirth Elektronik Capacitor Part Number 861141484010 Online
Purchase the Wirth Elektronik WCAP-AI3H aluminum electrolytic capacitor online today. With 120 uF capacity at 450 V DC and operating temperature from -25°C to +105°C, it is ideal for industrial power supplies and energy storage projects. Its durable aluminum casing, safety vent, and polarity markings ensure safe and reliable operation in demanding environments. RoHS and REACh compliant, this high-quality capacitor provides excellent ripple current handling of up to 800 mA, ensuring stable voltage regulation and long-term durability for your electronic systems.
Order your Wirth Elektronik WCAP-AI3H aluminum electrolytic capacitor today and enhance your power circuits with reliable voltage filtering and energy storage.
