WURTH ELEKTRONIK 865060340001 Aluminum Electrolytic Capacitor
This aluminum electrolytic capacitor is designed for use in general electronic equipment, offering reliable performance up to 105°C with a rated voltage of 16V. It features a capacitance of 10uF ±20%, with low leakage current and high ripple current capabilities at 105°C. Its compact size of 4.0 x 5.5 mm makes it suitable for space-constrained applications. The capacitor complies with RoHS & REACH standards and undergoes extensive safety and reliability testing to ensure optimal performance in electronic circuits requiring stable energy storage and filtering functions.
WURTH ELEKTRONIK 865060340001 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 10uF ±20%
- Rated Voltage: 16V
- Leakage Current: 3.0 HA max. after 2 min.
- Dissipation Factor: 16% typ. at 120Hz
- Ripple Current: 90 mA max. at 105°C, 100kHz
- Impedance: 1.35 Q max. at 20°C, 100kHz
- Operating Temperature: -55°C to +105°C
- Load Life: 2000 hours at +105°C/16V
- Storage Conditions: 35°C, <45% RH
- Dimensions: 4.0 x 5.5 mm
- RoHS & REACH compliant, RoHS & REACH certified
- Soldering: Reflow profile with peak at 217°C, preheat 150°C to 200°C, maximum ramp up/down rates of 3°C/s and 6°C/s respectively.
- Polarity: Negative terminal marked with a semicircle or bar on top.
- Design safety warnings for overvoltage, polarity, storage, and disposal.
Buy the WURTH ELECTRONIK 865060340001 – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Secure the WURTH ELECTRONIK aluminum electrolytic capacitor with 10uF capacitance and 16V rating today. Its compact size of 4.0 x 5.5 mm makes it ideal for space-conscious electronics, offering excellent ripple current handling, low leakage, and high stability up to 105°C. Fully RoHS and REACH compliant, this capacitor is perfect for energy storage, filtering, and decoupling in various industrial and consumer devices. Order online now for fast delivery and reliable performance in critical electronic applications.
Buy WURTH ELECTRONIK 865060340001 now and experience unmatched reliability and performance in your electronic designs.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 865060340001?
You can click on the BUY or RFQ button to purchase 865060340001 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 865060340001?
You can download the 865060340001 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 865060340001?
WURTH ELEKTRONIK
