WURTH ELEKTRONIK 865060640002 Aluminum Electrolytic Capacitor
This aluminum electrolytic capacitor is designed for general electronic applications requiring reliable power filtering and energy storage. With a capacitance of 2.2 uF rated at 50V, it features a maximum operating temperature of -55°C to +105°C and a load life of 2000 hours at +105°C/50V. The capacitor offers excellent ripple current handling, low impedance, and stable electrical characteristics, making it ideal for power supplies, DC/DC converters, and filtering circuits in industrial, automotive, and consumer electronics. Its compact size ensures easy integration into space-constrained designs, while high-quality materials ensure reliability and longevity in diverse working conditions.
WURTH ELEKTRONIK 865060640002 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 2.2 uF
- Rated Voltage: 50 V
- Operating Temperature Range: -55°C to +105°C
- Load Life: 2000 hours @ +105°C/50V
- Dissipation Factor: 12% at 120Hz
- Leakage Current: 3.0 μA max after 2 min.
- Impedance: 2.90 Ω at 100kHz @20°C
- Ripple Current: 60 mA max at 100kHz @105°C
- Physical Size: 4.0 x 5.5 mm
- Storage Conditions: 35°C, <45% RH
- Polarity: Negative terminal marked, polarity must be observed
- Reflow Profile: Max peak temperature 260°C, Preheat 150°C-200°C, Time above Tsp 60-150 sec.
- RoHS & REACH compliant
- Application: Power filtering, energy storage, DC/DC conversion, industrial electronics
Buy the Buy Wurth Elektronik Capacitor Part Number 865060640002 Online
Order the Wurth Elektronik aluminum electrolytic capacitor with part number 865060640002 today and enhance your electronic designs. This reliable component offers 2.2 uF capacitance at 50V, operating from -55°C to +105°C, with a load life of 2000 hours at +105°C/50V. Its compact size fits easily into space-constrained environments, making it ideal for power supply filtering, energy storage, and industrial electronics. Purchase online for fast delivery and ensure your project benefits from high-quality components with proven performance, longevity, and safety in demanding conditions.
Buy Wurth Elektronik capacitor with part number 865060640002 now and experience unmatched reliability and performance in your electronic applications.
Frequently Asked Questions
Where can I buy WURTH ELEKTRONIK 865060640002?
You can click on the BUY or RFQ button to purchase 865060640002 from an authorized WURTH ELEKTRONIK distributor.
How do I troubleshoot issues or seek technical support for part 865060640002?
You can download the 865060640002 datasheet or visit the WURTH ELEKTRONIK website for support.
Who is the manufacturer of 865060640002?
WURTH ELEKTRONIK
