WAGO 20023201 Triple-deck Terminal Block
The WAGO 2002-3201 is a versatile triple-deck terminal block ideal for industrial applications requiring reliable and space-efficient connections. It's designed for mounting on DIN rails (35 x 15 and 35 x 7.5) and utilizes the Push-in CAGE CLAMP® technology for secure and easy conductor termination. The block is rated for 500V and 24A, and is suitable for Ex e II applications, making it suitable for hazardous environments. It supports a wide range of conductor materials and sizes, ensuring compatibility with various wiring configurations. Its robust construction and multiple connection points make it a dependable choice for power distribution and signal transmission in industrial control panels and machinery.
WAGO 20023201 Triple-deck Terminal Block Specifications:
- Rated voltage (III / 3): 500 V
- Rated impulse voltage (III / 3): 6 kV
- Rated current: 24 A
- Rated current (2): 28 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 20 A
- Rated voltage UL (Use Group C): 300 V
- Rated current UL (Use Group C): 20 A
- Rated voltage UL (Use Group D): 600 V
- Rated current UL (Use Group D): 5 A
- Rated voltage CSA (Use Group B): 600 V
- Rated current CSA (Use Group B): 20 A
- Rated voltage CSA (Use Group C): 600 V
- Rated current CSA (Use Group C): 20 A
- Rated voltage EN (Ex e II): 440 V
- Rated current (Ex e II): 19 A
- Rated current (Ex e II) with jumper: 17 A
- Connection technology: Push-in CAGE CLAMP®
- Number of connection points (connection type): 3
- Actuation type: Push-in
- Connectable conductor materials: Copper
- Nominal cross section: 2.5 mm²
- Solid conductor: 0.25 … 4 mm² / 22 … 12 AWG
- Solid conductor, push-in termination: 0.75 … 4 mm² / 18 … 12 AWG
- Fine-stranded conductor: 0.25 … 4 mm² / 22 … 12 AWG
- Fine-stranded conductor with ferrule with plastic collar: 1 … 2.5 mm² / 18 … 12 AWG
- Fine-stranded conductor with ferrule, push-in termination, from: 1 … 2.5 mm² / 18 … 12 AWG
- Strip length: 10 … 12 mm / 0.39 … 0.47 inch
- Number of connection points: 3
- Total number of connection points: 6
- Total number of potentials: 3
- Number of levels: 3
- Type of wiring: Front-entry wiring
- Width: 5.2 mm / 0.205 inch
- Height from upper-edge of DIN-35 rail: 69.5 mm / 2.736 inch
- Depth: 93.3 mm / 3.673 inch
- Design: horizontal
- Type of mounting: DIN-35 rail
- Potential marking: L/L/L
- Marking level: Center/side marking
- Insulating material: Polyamide 66 (PA 66)
- Fire load: 0.316 MJ
- Weight: 16.8 g
- Product Group: 22 (TOPJOB S)
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918691185
- Customs Tariff No.: 85369010000
Buy the 2002-3201 WAGO Triple-deck Terminal Block | myMectronic
Purchase the WAGO 2002-3201 terminal block securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 20023201?
You can click on the BUY or RFQ button to purchase 20023201 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 20023201?
You can download the 20023201 datasheet or visit the WAGO website for support.
Who is the manufacturer of 20023201?
WAGO
