WAGO 20911423005000 3-pole Male Header
The WAGO 2091-1423/005-000 is a 3-pole male header designed for versatile panel feedthrough applications. Its angled design and clamping collar ensure secure and reliable connections. The header allows for the assembly of female connectors, enabling the division of functions within a single male header. Coding pins prevent mismating, making it suitable for applications requiring coding in panel feedthroughs. It offers vibration resistance up to 20g and is compatible with various PCB design software.
WAGO 20911423005000 3-pole Male Header Specifications:
- Pin Spacing: 3.5 mm
- Number of Poles: 3
- Solder Pin Length: 3.6 mm
- Solder Pin Diameter: 1 mm
- Drilled Hole Diameter: 1.2 mm
- Rated Voltage (III/3): 160 V
- Rated Surge Voltage (III/3): 2.5 kV
- Rated Current: 10 A
- Material Group: I
- Insulation Material: Polyphthalamide (PPA GF)
- Flammability Class: V0
- Contact Material: Electrolytic Copper (E Cu)
- Contact Plating: tin-plated
- Operating Temperature Range: -60 … +100 °C
- Width: 24.5 mm
- Height: 16 mm
- Height from Surface: 12.4 mm
- Depth: 17.5 mm
