WAGO 231110026000 10 Pole Female Plug Connector
The WAGO 231-110/026-000 is a 10-pole female plug connector designed for use in multi-circuit systems. It utilizes WAGO’s innovative CAGE CLAMP® connection technology, ensuring a secure and vibration-resistant connection without the need for special tools. The integrated fixing flanges provide additional stability when mounted, while the coding fingers prevent incorrect connections. This connector is ideal for applications in control cabinets, automation systems, and power distribution panels where reliable and efficient connections are essential. It supports a wide range of wire gauges and voltage ratings, making it a versatile choice for diverse industrial needs.
WAGO 231110026000 10 Pole Female Plug Connector Specifications:
- packing_unit: 50 pieces
- pin_spacing: 5 mm / 0.197 in
- pole_count: 10
- cross_section_min_mm2: 0.08
- cross_section_max_mm2: 2.5
- cross_section_min_awg: 28
- cross_section_max_awg: 12
- connection_method: CAGE CLAMP®CONNECTION
- measured_voltage_en: 250 V
- measured_shock_voltage: 4 kV
- pollution_degree: 3
- current_intensity_en: 16 A
- weight: 18 g
- color: grey
- no_of_connection_points: 10
- no_of_potentials: 10
- height: 14.3 mm
- height_in: 0.563 in
- width: 51.5 mm
- width_in: 2.028 in
- depth: 26.45 mm
- depth_in: 1.041 in
- strip_length_min_mm: 8
- strip_length_max_mm: 9
- strip_length_min_in: 0.33
- abs_approval_no: 04-HG469925-PDA
- bv_approval_no: 11915/A0
- cca_approval_no: 5764
- csa_approval_no: 154112-1466354
- demko_approval_no: 88126
- gl_approval_no: 17296-00HH
- kema_approval_no: 2083746.02
- kr_approval_no: HMB05880-EL003
- lr_approval_no: 91/20112(E3)
- rmr_approval_no: 11130002
- ur_approval_no_1: E45171
- ur_approval_no_2: E45172
- voltage_abs: 400 V
- voltage_bv: 400 V
- voltage_cca: 250 V
- voltage_csa: 300 V
- voltage_demko: 250 V
- voltage_gl: 400 V
- voltage_kema: 250 V
- voltage_kr: 250/400 V
- voltage_lr: 400 V
- voltage_rmr: 400 V
- voltage_ur_1: 600 V
- voltage_ur_2: 300 V
- current_abs: 16 A
- current_bv: 16 A
- current_cca: 16 A
- current_csa: 15 A
- current_demko: 16 A
- current_gl: 16 A
- current_kema: 16 A
- current_kr: 12/16 A
- current_lr: 16 A
- current_rmr: 16 A
- current_ur_1: 15 A
- current_ur_2: 15 A
