WAGO 231264001000 Straight Solder Pin Header
The WAGO 231-264/001-000 is a 4-pole header designed for robust and reliable connections in industrial environments. Its straight solder pin configuration and 7.5mm pin spacing facilitate easy integration into PCB layouts. The closed end design and perpendicular mating direction offer precise alignment and secure connections. This header is suitable for applications requiring a compact and durable connection solution, commonly found in automation, control systems, and power distribution.
WAGO 231264001000 Straight Solder Pin Header Specifications:
- product_description: HEADER; STRAIGHT SOLDER PIN, 1.2 X 1.2 MM /0.047 X 0.047 IN; 4 POLE; PIN SPACING 7.5 MM / 0.295 IN; WITH CLOSED END; MATING DIRECTION PERPENDICULAR TO PCB
- packing_unit: 100 pieces
- product_group: Multi Conn. System
- pin_spacing_mm: 7.5
- pin_spacing_in: 0.295
- pole_count: 4
- measured_voltage_en: 400 V
- measured_shock_voltage: 6 kV
- pollution_degree: 3
- current_intensity_en: 16 A
- weight_g: 1.93
- color: grey
- height_mm: 12
- height_in: 0.472
- width_mm: 30.5
- width_in: 1.201
- depth_mm: 8.4
- depth_in: 0.331
- approval_abs: 04-HG469925-PDA
- approval_bv: 11915/A0
- approval_cca: 5764
- approval_csa: 154112-1466354
- approval_demko: 88126
- approval_gl: 17296-00HH
- approval_kema: 2083746.02
- approval_lr: 96/20035
- approval_nemko: P94101840
- approval_rmr: 11130002
- approval_ur_e45171: 600
- approval_ur_e45172: 300
- cross_section_mm2: 2.5
- cross_section_dimension: 1.2x1.2
