WAGO 231302026000 Female Connector 2 Pole
The WAGO 231-302/026-000 is a robust 2-pole female connector designed for use in a wide range of industrial applications. Featuring a 5.08mm pin spacing and closed-end coding fingers, it ensures secure and reliable connections. The CAGE CLAMP® connection system allows for easy and vibration-proof termination of conductors ranging from 0.08 to 2.5 mm² solid and fine-stranded. It is suitable for applications requiring a compact and dependable connection solution, commonly found in control cabinets, machinery, and automation systems. The connector is RoHS compliant and offers a wide range of approvals including ABS, BV, CSA, and KEMA.
WAGO 231302026000 Female Connector 2 Pole Specifications:
- product_description: FEMALE CONNECTOR 2 POLE PIN SPACING 5.08 MM / 0.2 IN WITH CODING FINGERS CLOSED END
- packing_unit: 100 pieces
- color: orange
- no_of_connection_points: 2
- no_of_potentials: 2
- pole_count: 2
- height: 14.3 mm
- height_in: 0.563 in
- width: 11.66 mm
- width_in: 0.459 in
- depth: 26.45 mm
- depth_in: 1.041 in
- pin_spacing: 5.08 mm
- pin_spacing_in: 0.2 in
- pollution_degree: 2
- measured_voltage_en: 630 V
- measured_shock_voltage: 4 kV
- current_intensity_en: 16 A
- connection_method: CAGE CLAMP® CONNECTION
- cross_section_mm2_solid: 0.08 - 2.5 mm²
- cross_section_mm2_fine_stranded: 0.08 - 2.5 mm²
- cross_section_mm2_ferrule_plastic_collar: 0.25 - 1.5 mm²
- cross_section_mm2_ferrule_no_collar: 0.25 - 2.5 mm²
- cross_section_awg: 28 - 12 AWG
- strip_length_mm: 8 mm
- strip_length_mm_to: 9 mm
- contact_material: Copper base alloy tin-plated
- material_group: Strain relief plate
- strain_relief_plate_length_mm: 11,5 mm
- abs_approval_no: 04-HG469925/1-PDA
- bv_approval_no: 11915/A0
- cca_approval_no: 5764
- csa_approval_no: 154112-1466354
- gl_approval_no: 17296-00HH
- kema_approval_no: 2083746.02
- kr_approval_no: HMB05880-EL003
- lr_approval_no: 96/20035
- rmr_approval_no: 11130002
- ur_approval_no_1: E45171
- ur_approval_no_2: E45172
