WAGO 231307026000 7-pole female plug connector
The WAGO 231-307/026-000 is a 7-pole female plug connector designed for versatile applications in industrial automation and control systems. It utilizes WAGO's innovative CAGE CLAMP technology, enabling easy and secure connection of various conductor types, including solid, stranded, and ferruled conductors. The integrated test ports facilitate convenient circuit testing and troubleshooting. This connector is part of the MULTI CONNECTION SYSTEM (MCS) and is designed to be operated with appropriate operating tools. It is RoHS compliant and offers reliable performance in demanding environments.
WAGO 231307026000 7-pole female plug connector Specifications:
- Color: orange
- Conductor size: 0.08 … 2.5 mm² / 28 … 12 AWG
- Number of poles: 7
- Pin spacing: 5.08 mm / 0.2 inch
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 16 A
- Material: Polyamide 66 (PA 66)
- Flammability class: V0
- Weight: 12.9 g
- Operating temperature: -60 … +85 °C
- Connection technology: CAGE CLAMP®
- Width: 37.06 mm / 1.459 inch
- Height: 14.3 mm / 0.563 inch
- Depth: 26.45 mm / 1.041 inch
Buy the 231-307/026-000 WAGO 7-pole female plug connector | myMectronic
Purchase the WAGO 231-307/026-000 connector securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 231307026000?
You can click on the BUY or RFQ button to purchase 231307026000 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 231307026000?
You can download the 231307026000 datasheet or visit the WAGO website for support.
Who is the manufacturer of 231307026000?
WAGO
