WAGO 231605 5-pole Male Connector
The WAGO 231-605 is a robust 5-pole male connector ideal for use in industrial automation, control systems, and power distribution. It utilizes WAGO’s CAGE CLAMP® connection technology for secure and vibration-resistant terminations. The connector supports a broad range of wire sizes, from 0.08 mm² to 2.5 mm², and is designed to operate within a temperature range of -60°C to +100°C. Its nickel-chromium spring steel clamping spring and electrolytic copper contact with tin plating ensure long-term reliability and performance. Multiple approvals including ABS, BV, CSA, and UL are available.
WAGO 231605 5-pole Male Connector Specifications:
- product_description: Male connector 5-pole
- pin_spacing: 5 mm / 0.197 in
- packing_unit: 50 pieces
- no_of_connection_points: 5
- no_of_potentials: 5
- pole_count: 5
- height: 14.3 mm / 0.563 in
- width: 28.2 mm / 1.11 in
- depth: 27.5 mm / 1.083 in
- rating_iec_en_60664_1: Overvoltage category EN I III
- pollution_degree: 2
- measured_voltage_en: 320 V
- measured_shock_voltage: 4 kV
- current_intensity_en: 12 A
- overvoltage_category_en_ii: II
- current_intensity_en_2: 12 A
- measured_voltage_en_630: 630 V
- current_intensity_en_12: 12 A
- rated_voltage_en: 320 V
- rated_surge_voltage: 4 kV
- nominal_current: 12 A
- connection_method: CAGE CLAMP®CONNECTION
- cross_section_mm2_1: 0.08 - 2.5 mm²
- wiring_method_solid: solid
- cross_section_mm2_2: 0.08 - 2.5 mm²
- wiring_method_fine_stranded: fine-stranded
- cross_section_mm2_3: 0.25 - 1.5 mm²
- wiring_method_ferrule_plastic: fine-stranded (with ferrule and plastic collar)
- cross_section_mm2_4: 0.25 - 2.5 mm²
- wiring_method_ferrule_no_plastic: fine-stranded (with ferrule, without plastic collar)
- cross_section_awg: 28 - 12 AWG
- strip_length_from: 8 mm
- strip_length_to: 9 mm
- strip_length_from_inch: 0.31 in
- strip_length_up_to_inch: 0.35 in
- insulating_material: I PA 6.6
- temperature_stability: -60 °C to +100 °C
- flammability_category_ul94: V0
- clamping_spring_material: Nickel-chromium spring steel (CrNi)
- contact_material: Electrolytic copper (Ecu)
- contact_plating: tin-plated
- strain_relief_plate: 20 mm
- abs_approval_no: 04-HG469925/1-PDA
- bv_approval_no: 11915/A0
- cca_approval_no: 5764
- csa_approval_no: 154112-1466354
- gl_approval_no: 17296-00HH
- kema_approval_no: 2083746.02
- kr_approval_no: HMB05880-EL003
- lr_approval_no: 96/20035
- rmr_approval_no: 11130002
- ur_approval_no_1: E45171
- ur_approval_no_2: E45172
