WAGO 231624019000 24 Pole Connector Block
The WAGO 231-624/019-000 is a 24-pole connector block designed for reliable power and signal transmission in industrial environments. It incorporates a fixing flange for secure mounting and utilizes the innovative cage clamp connection technology, simplifying wiring and ensuring robust connections. This connector block is suitable for screw or similar mounting types and is ideal for applications requiring a compact and efficient connection solution. It is designed to handle voltages up to 400V and currents up to 16A, making it suitable for a wide range of applications.
WAGO 231624019000 24 Pole Connector Block Specifications:
- Product Description: Male connector with fixing flange, 24 pole, pin spacing 5 mm / 0.197 in, cage clamp connection, for screw or similar mounting types
- Packing Unit: 10 pieces
- Product Group: Multi Conn. System
- Pin Spacing: 5 mm / 0.197 in
- Pole Count: 24
- Cross Section Range (mm²): 0.08 - 2.5
- Cross Section Range (AWG): 28 - 12 AWG
- Connection Method: Cage Clamp® Connection
- Measured Voltage: 250 V
- Measured Shock Voltage: 4 kV
- Pollution Degree: 3
- Current Intensity: 12 A
- Weight: 37.38 g
- Color: grey
- Number of Connection Points: 24
- Number of Potentials: 24
- Height: 14.3 mm / 0.563 in
- Width: 134.8 mm / 5.307 in
- Depth: 27.5 mm / 1.083 in
- Strip Length: 8 - 9 mm / 0.33 in
- Approval ABS: 04-HG469925-PDA, 400V, 12A, 5.0mm²
- Approval BV: 11915/A0, 400V, 16A, 2.5mm²
- Approval CCA: 5764, 250V, 12A, 0.08-2.5mm²
- Approval CSA: 154112-1466354, 300V, 15A, 22-12 AWG
- Approval DEMKO: 88126, 250V
- Approval GL: 17296-00HH, 400V, 12A, 5.0mm²
- Approval KEMA: 2083746.02, 250V, 12A, 0.08-2.5mm²
- Approval KR: HMB05880-EL003, 250/400V, 12/16A, 2.5mm²
- Approval LR: 96/20035, 400V, 12A, 5.0mm²
- Approval NEMKO: P94101840, 250V
- Approval RMR: 11130002, 400V, 12A, 5.0mm²
- Approval UR: E45171, 600V, 15A, 12 AWG
- Approval UR2: E45172, 300V, 15A, 22-12 AWG
